AX-ADXSVI-CH3 AX-ADXSVI-CH3

Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com

INSTALLATION INSTRUCTION SINSTALLATION INSTRUCTION S

Dodge/RAM accessory and NAV output CAN harness 2013-up

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-ampliﬁed systems or when replacing ampliﬁed system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired ASWC-1 harness included (ASWC-1 sold separately)

• Retains back-up camera (if through the OE radio)

• Retains the use of the 3.5mm AUX jack

• High level speaker input

• USB updatable

Note:

This harness must be used along with the AX-ADXSVI

DODGE

Dart

(small screen option) 2013-2016

RAM

1500, 2500, 3500

(small screen option) 2013-up

Chassis cab 3500, 4500, 5500

(small screen option) 2013-up

APPLICATIONS

WIRING THE AX-ADXSVI-CH3

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the wire to the radio’s ground wire.Black

• Connect the wire to the ignition wire of the aftermarket radio.Red

• Connect the wire to the illumination wire of the aftermarket radio. If the Orange

aftermarket radio has no illumination wire, tape off the wire.Orange

•

Connect the wire to the left front positive speaker output of the aftermarket radioWhite

• Connect the wire to the left front negative speaker output of the aftermarket radio.White/Black

• Tape off and disregard the following (1) wire, will not be used in this application:

Blue/White labeled "500L amp turn on"

• Connect the wire to the right front positive speaker output of the aftermarket radio.Gray

•

Connect the Gray/Black wire to the right front negative speaker output of the aftermarket radio

• Connect the wire to the radio’s left rear positive speaker output.Green

• Connect the wire to the radio’s left rear negative speaker output.Green/Black

• Connect the wire to the radio’s right rear positive speaker output.Purple

• Connect the wire to the radio’s right rear negative speaker output.Purple/Black

The following wires are for the aftermarket radios that have navigation built in.

• Connect the wire to the parking brake wire of the aftermarket navigation radio (if applicable).Light Green

•

Connect the wire to the VSS or speed sense wire of the aftermarket navigation radio (if applicable).Blue/Pink

• Connect the wire to the reverse wire of the aftermarket navigation radio (if applicable).Green/Purple

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to test the radio.

•

Tape off and disregard the following (1) wire, will not be used in this application:

Blue/White

labeled "500L amp turn on".

RCA CONNECTIONS

•

Connect the Yellow RCA to the "video in" of the aftermarket radio to retain the OE back up camera (if equipped).

• Connect the and RCA to the audio "AUX in" of the aftermarket radio to retain the OE 3.5mm jack White Red

(if equipped).

ASWC-1 (IF INSTALLING)

After the XSVI is initialized, plug in the ASWC-1 into the 12-pin harness of the AX-ADXSVI-CH3

and refer to the

ASWC-1 instructions.

K PNOWLEDGE IS OWER

Enhance your inst allat ion and fabricat ion skills by

enrolling in t he most recog nized and spect ed re

mobile elect nics school in our indust ry.ro

Log ont o www.inst allerinst itut e.com or cal l

800-354-6782 for m o informat ion and t ake steps re

t oward a bet t er tomorrow.

Metra recommends MECP

certiﬁed technicians

CAUTION!

All accessories, switches, climate controls

panels, and especially air bag indicator lights must

be connected before cycling the ignition. Also, do

not remove the factory radio with the key in the on

position, or while the vehicle is running.
