Side 1/5
INSTAX-ADXSVI-FD1
© COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 2/23/15
AX-ADXSVI-FD1
Ford accessory and NAV output CAN harness 2007-up
• Providesaccessory(12volt10amp)
• RetainsR.A.P.(retainedaccessorypower)
• Usedinnon-amplifiedsystems,orwhenreplacingamplifiedsystem
• ProvidesNAVoutputs(parkingbrake,reverse,andV.S.S.)
• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)
• Highlevelspeakerinput
• USBupdatable
Note: ThisharnessmustbeusedinconjunctionwiththeAX-ADXSVI.
FORD
Edge 2007-2010
Escape 2008-2012
Expedition 2007-2014
Flex 2008-2012
Focus 2008-2011
Fusion 2010-2012
F-150 2009-2012
F150STX/FX2base/XLTbase 2013
F150STX/XLTbase 2014
F250/350/450/550 2008-2012
F250/350/450/550(XL/XLT) 2013-up
Mustang 2009-2014
Taurus 2010-2012
LINCOLN
MKX 2007-2010
MKZ 2007-2009
Navigator 2007-2014
(only to be used when replacing an amplified system)
MAZDA
Tribute 2008-2011
MERCURY
Mariner 2008-2011
Milan 2010-2011
APPLICATIONS
WIRING UP THE AX-ADXSVI-FD1
• ConnecttheYellowwiretotheradio’s12voltbatteryormemorywire.
• Connectthe wiretotheradio’sgroundwire.Black
• Connectthe wiretotheignitionwireoftheaftermarketradio.Red
• Connectthe wiretotheilluminationwireoftheaftermarketradio.IftheaftermarketOrange
radiohasnoilluminationwire,tapeofftheorangewire.
• Connectthe wiretotheantennaturnonwireoftheaftermarketradio. Blue
• Connectthe wiretotheleftfrontpositivespeakeroutputoftheaftermarketradio.White
INSTAX-ADXSVI-FD1
© COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 2/23/15
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
K PNOWLEDGE IS OWER
Enhance your inst allat ion and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo informat ion and t ake steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
• Connectthe wiretotheleftfrontnegativespeakeroutputoftheWhite/Black
aftermarketradio.
• Connectthe wiretotherightfrontpositivespeakeroutputoftheaftermarketradio.Gray
• Connectthe wiretotherightfrontnegativespeakeroutputoftheGray/Black
aftermarketradio.
• Connectthe wiretotheradio’sleftrearpositivespeakeroutput.Green
• Connectthe wiretotheradio’sleftrearnegativespeakeroutput.Green/Black
• Connectthe wiretotheradio’srightrearpositivespeakeroutput. Purple
• Connectthe wiretotheradio’srightrearnegativespeakeroutput. Purple/Black
Thefollowingwiresarefortheaftermarketradiosthathavenavigationbuiltin.
• Connectthe wiretotheparkingbrakewireoftheaftermarketnavigation Light Green
radio(ifapplicable).
• Connectthe wiretotheVSSorspeedsensewireoftheaftermarketnavigationBlue/Pink
radio(ifapplicable).
• Connectthe wiretothereversewireoftheaftermarketnavigationradio Green/Purple
(ifapplicable).
• Cyclethekeybyturningtheignitiononfor30seconds,then“off”and“on”againto 
testtheradio.
AX-ADXSVI-FD1 SUB PLUG WIRING
•Connectthe(2)Blue/Whitewirestotheampturnonoftheaftermarketradio.
•ConnecttheRedRCAjacktotherightsubwooferoutputoftheaftermarketradio.
•ConnecttheWhiteRCAjacktotheleftsubwooferoutputoftheaftermarketradio.
ASWC-1 (if installing)
AftertheXSVIisinitialized,plugintheASWCintothe12-pinharnessoftheAX-ADXSVI-FD1and
refertotheASWCinstructions.
