INSTAX-ADXSVI-FT1

1-800-221-0932 metraonline.com

REV. 12/17/13

AX-ADXSVI-FT1

Fiat 500 accessory and NAV output CAN interface 2012-up

• Provides accessory (12 volt 10 amp)    

• Retains R.A.P.   (retained accessory power)

• Usedinbothamplifiedandnon-amplifiedsystems

• Provides outputs (parking brake, reverse, NAV     and V.S.S.)

• Prewired ASWC-1 harness included (ASWC-1 sold separately)     

• High level speaker input  

• Retains OE BT/USB and 3.5mm audio    

• USB updateble

Note: This harness must be used in conjunction with the AX-ADXSVI        

APPLICATIONS

FIAT

500 2012-up

WIRING UP THE AX-ADXSVI-FT1

• ConnecttheYellowwiretotheradio’s12voltbatteryormemorywire.

• Connectthe wiretotheradio’sgroundwire.Black

• Connectthe wiretotheignitionwireoftheaftermarketradioRed

• Connectthe wiretotheilluminationwireoftheaftermarketradio.IftheOrange

aftermarketradiohasnoilluminationwire,tapeoffthe wire.Orange

• Connectthe wiretotheradio'sampturnonwire. Blue/White

• Connectthe wiretotheleftfrontpositivespeakeroutputoftheWhite

aftermarketradio.

• Connectthe wiretotheleftfrontnegativespeakeroutputoftheWhite/Black

aftermarketradio.

INSTAX-ADXSVI-FT1

1-800-221-0932 metraonline.com

REV. 12/17/13

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

K PNOWLEDGE IS OWER

Enhance your inst allat ion and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take steps re

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

• Connectthe wiretotherightfrontpositivespeakeroutputoftheGray

aftermarketradio.

• Connectthe wiretotherightfrontnegativespeakeroutputoftheGray/Black

aftermarketradio.

• Connectthe wiretotheradio’sleftrearpositivespeakeroutput.Green

• Connectthe wiretotheradio’sleftrearnegativespeakeroutput.Green/Black

• Connectthe wiretotheradio’srightrearpositivespeakeroutput. Purple

• Connectthe wiretotheradio’srightrearnegativespeakeroutput. Purple/Black

Thefollowingwiresarefortheaftermarketradiosthathavenavigationbuiltin.

• Connectthe wiretotheparkingbrakewireoftheaftermarketnavigation Light Green

radio(ifapplicable).

• Connectthe wiretotheVSSorspeedsensewireoftheaftermarketBlue/Pink

navigationradio(ifapplicable).

• Connectthe wiretothereversewireoftheaftermarketnavigationradio Green/Purple

(ifapplicable).

• PlugtheAUX/3.5mmorBT/USBRCAstotheaftermarketradio'saudioAUXinput.

• Cyclethekeybyturningtheignitiononfor30seconds,then“off”and“on”againto

testtheradio.

ASWC-1 (if installing)

AftertheXSVIisinitialized,plugintheASWCintothe12pinharnessofthe 

AX-ADXSVI-FT1andrefertotheASWCinstructions.
