Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION

1-800-221-0932 axxessinterface.com

© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION

1-800-221-0932 axxessinterface.com

© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION

1-800-221-0932 axxessinterface.com

© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION

1-800-221-0932 axxessinterface.com

© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION

1-800-221-0932 axxessinterface.com

© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION

1-800-221-0932 axxessinterface.com

The is designed to convert 4 channels AX-ALOC648

of speaker level audio to line level audio. This allows

for the installation of line level products such as

ampliers, EQs and crossovers on stereo heads that

do not have RCA line level outputs.

Features:

80 Watts maximum input, input circuit corrects

crossover distortion commonly found on other brands

of locs, 6:1 step down with variable output, detachable

input plug, gold ashed rcas, attractive & durable

enclosure.

4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

The is designed to convert 4 channels AX-ALOC648

of speaker level audio to line level audio. This allows

for the installation of line level products such as

ampliers, EQs and crossovers on stereo heads that

do not have RCA line level outputs.

Features:

80 Watts maximum input, input circuit corrects

crossover distortion commonly found on other brands

of locs, 6:1 step down with variable output, detachable

input plug, gold ashed rcas, attractive & durable

enclosure.

4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

The is designed to convert 4 channels AX-ALOC648

of speaker level audio to line level audio. This allows

for the installation of line level products such as

ampliers, EQs and crossovers on stereo heads that

do not have RCA line level outputs.

Features:

80 Watts maximum input, input circuit corrects

crossover distortion commonly found on other brands

of locs, 6:1 step down with variable output, detachable

input plug, gold ashed rcas, attractive & durable

enclosure.

4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

The is designed to convert 4 channels AX-ALOC648

of speaker level audio to line level audio. This allows

for the installation of line level products such as

ampliers, EQs and crossovers on stereo heads that

do not have RCA line level outputs.

Features:

80 Watts maximum input, input circuit corrects

crossover distortion commonly found on other brands

of locs, 6:1 step down with variable output, detachable

input plug, gold ashed rcas, attractive & durable

enclosure.

4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

The is designed to convert 4 channels AX-ALOC648

of speaker level audio to line level audio. This allows

for the installation of line level products such as

ampliers, EQs and crossovers on stereo heads that

do not have RCA line level outputs.

Features:

80 Watts maximum input, input circuit corrects

crossover distortion commonly found on other brands

of locs, 6:1 step down with variable output, detachable

input plug, gold ashed rcas, attractive & durable

enclosure.

4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

The is designed to convert 4 channels AX-ALOC648

of speaker level audio to line level audio. This allows

for the installation of line level products such as

ampliers, EQs and crossovers on stereo heads that

do not have RCA line level outputs.

Features:

80 Watts maximum input, input circuit corrects

crossover distortion commonly found on other brands

of locs, 6:1 step down with variable output, detachable

input plug, gold ashed rcas, attractive & durable

enclosure.

4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

Produkt Specifikationer

Mærke:	AXESS
Kategori:	Ikke kategoriseret
Model:	AX-ALOC648

Har du brug for hjælp?

Hvis du har brug for hjælp til AXESS AX-ALOC648 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret AXESS Manualer

AXESS AXBUCH-MZ6V Manual

29 Juli 2025

AXESS AXABH-CH3 Manual

29 Juli 2025

AXESS AXDSPX-HK5 Manual

25 Februar 2025

AXESS AXAMP-CH8 Manual

25 Februar 2025

AXESS AXTC-MZ1 Manual

25 Februar 2025

AXESS AXBUCH-TYCAM26V Manual

25 Februar 2025

AXESS AXAMP-FD2 Manual

25 Februar 2025

AXESS AXBUCH-TYCAM36V Manual

25 Februar 2025

AXESS AXAMP-TY1 Manual

25 Februar 2025

AXESS AXAMP-TY4 Manual

25 Februar 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Advantech MIC-711-OX Manual

30 Juli 2025

Intellinet 713108 Manual

30 Juli 2025

Electro Harmonix

Electro Harmonix EU12AC-1000 Manual

30 Juli 2025

Advantech PCIE-1753 Manual

30 Juli 2025

MXR Rockman X100 Manual

30 Juli 2025

MIPRO MI-909R Manual

30 Juli 2025

Advantech AMAX-4870 Manual

30 Juli 2025

Advantech IDK-1112P-50XGA2 Manual

30 Juli 2025

MIPRO MP-820 Manual

30 Juli 2025

Advantech ARES-12290 Manual

30 Juli 2025
