AX-PS
AX-PS
I N S T A L L A T I O N I N S T R U C T I O N S
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. INSTAX-PS4/11/23
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. INSTAX-PS4/11/23
A
B
AX-PS
INTERFACE COMPONENTS
• AX-PS Timer with wiring harness
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
Universal-Amp Turn On/Off Timer
SETUP/SETTINGS
(Timer settings 0-30 seconds*)
*Turn-On Delay
•
Press left button (A) to enter the Turn-On delay setting,
the . Red LED flashes
•
Press left (A) and right (B) button to set up the delay, up to 30 seconds. If there is no
action for 3 seconds, it will return to display mode.
*Turn-Off Delay
• Press right button (B) to enter into Turn-Off Delay setting, the . Green LED flashes
• Press left
(A)
and right (B) button to set up the delay up to 30 seconds. If there is no
action for 3 seconds, it will return to display mode.
Note: Display will turn off after 3 minutes on inactivity. To turn on the display press
either the A or B button
Blue: Remote turn on output
Red: Remote turn on input
Yellow: 12v Constant
Black: Ground
SPECIFICATIONS
Working Voltage: 10v-16v
Trigger output current: 500mA
Trigger input Current: 1mA
TURN-ON DELAY (GREEN LED)
TURN-OFF DELAY (RED LED)
A
B
AX-PS
INTERFACE COMPONENTS
• AX-PS Timer with wiring harness
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
Universal-Amp Turn On/Off Timer
SETUP/SETTINGS
(Timer settings 0-30 seconds*)
*Turn-On Delay
•
Press left button (A) to enter the Turn-On delay setting,
the . Red LED flashes
•
Press left (A) and right (B) button to set up the delay, up to 30 seconds. If there is no
action for 3 seconds, it will return to display mode.
*Turn-Off Delay
• Press right button (B) to enter into Turn-Off Delay Green LED flashes setting, the .
• Press left
(A)
and right (B) button to set up the delay up to 30 seconds. If there is no
action for 3 seconds, it will return to display mode.
Note: Display will turn off after 3 minutes on inactivity. To turn on the display press
either the A or B button
Blue: Remote turn on output
Red: Remote turn on input
Yellow: 12v Constant
Black: Ground
SPECIFICATIONS
Working Voltage: 10v-16v
Trigger output current: 500mA
Trigger input Current: 1mA
TURN-ON DELAY (GREEN LED)
TURN-OFF DELAY (RED LED)
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and spected re
mobile elect nics school in our industry.ro
Log onto www.installerinstitute.edu or call
386-672-5771 for mo information and take steps re
toward a better tomorrow.
®
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and spected re
mobile elect nics school in our industry.ro
Log onto www.installerinstitute.edu or call
386-672-5771 for mo information and take steps re
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
Metra recommends MECP
certified technicians
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. INSTAX-PS4/11/23
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. INSTAX-PS4/11/23
I N S T A L L A T I O N I N S T R U C T I O N S
I N S T A L L A T I O N I N S T R U C T I O N S
AX-PS
AX-PS
Having difficulties? We’re here to help.
Contact our Tech Support line at:
386-257-1187
Or via email at:
techsupport@metra-autosound.com
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
Having difficulties? We’re here to help.
Contact our Tech Support line at:
386-257-1187
Or via email at:
techsupport@metra-autosound.com
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
