AXADCT-4

INSTALL ATION INSTR UCTIONS

REV. 4/27/20

Integrate • AxxessInterfaces.com

Wire Color & Function: The audio and power input wire colors are an EIA standard for car

stereo applications as follows.

INPUT HARNESS POWER HARNESS

White LEFT Front (+) Input Yellow BATTERY +12V Input

White/Black LEFT Front (-) Input POWER (-) GROUND InputBlack

Gray RIGHT Front + Input REMOTE +12V OutputBlue

Gray/Black RIGHT Front (-) Input Reference Ground(-)Black/White

Green LEFT Rear (+) Input

Green/Black LEFT Rear (-) Input

Purple RIGHT Rear (+) Input

Purple/Black RIGHT Rear (-) Input

OUTPUT HARNESS

White LEFT Front (+) Output LEFT Rear (+) OutputGreen

White/Black LEFT Front (-) Output LEFT Rear (-) OutputGreen/Black

Gray RIGHT Front + Output RIGHT Rear (+) OutputPurple

Gray/Black RIGHT Front (-) Output RIGHT Rear (-) OutputPurple/Black

Note: Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXADCT-4. The same goes for the negative audio

wires. Failure to do this will result in poor bass response and low quality audio.

Adjusting the AXADCT-4 for maximum performance: After completing all of the necessary

connections, turn the AXADCT-4 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and adjust the main volume

control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment

pots on the AXADCT-4 and turn it slowly clockwise until you notice audio distortion and then

stop. Turn the remaining pots to the same position as the previously adjusted pot. The audio

set-up of the AXADCT-4 is now complete and ready to be enjoyed.
