Side 1/5

axxessinterfaces.com • metraonline.com

Axxess Integrate

REV. 1/28/20

Installation Instructions for AXBUCH-MI6V

INTERFACE FEATURES

• Retains the factory backup camera to an aftermarket radio

• Allows an aftermarket camera to be added to the factory screen

• Includes the AXCSD-6V 12-volt to 6-volt converter

INTERFACE COMPONENTS

• AXBUCH-MI6V harness • AXCSD-6V 12-volt to 6-volt converter

AXBUCH-MI6V

Mitsubishi Backup Camera Retain/Add-On

2014-Up

MITSUBISHI

Lancer 2014-Up

Lancer Sportback 2014-Up

Outlander 2014-Up

Outlander Sport 2014-Up

• Wire cutter • Crimping tool • Solder gun • Tape

• Connectors (example: butt connectors, bell caps, etc.)

APPLICATIONS

TOOLS REQUIRED

CAUTION!

All accessories, switches, climate controls panels, and especially air bag indicator lights

must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

axxessinterfaces.com • metraonline.com

Axxess Integrate

Installation Instructions for AXBUCH-MI6VInstallation Instructions for AXBUCH-MI6V

K PNOWLEDGE IS OWER

Enhance your installat ion and fabrica tion skills by

enrolling in the most recogniz ed and spected re

mobile elect nics s chool in our industry.ro

Log ont o www.installerinstit ute.com or call

800-354-6782 for mo information and t ake steps re

toward a bett er t omorrow.

Metra r ecommends MECP

certified technicians

Connections to be made

The AXBUCH-MI6V can be connected two different ways

To retain the factory backup camera to an aftermarket radio:

• Connect the wire to chassis ground, and also to the wire of the AXCSD-6V.Black Black

• Connect the Yellow wire to battery power.

•

Connect the wire to the wire of the AXCSD-6V.Red Blue/Red

• Connect the wire to the reverse wire of the aftermarket radio,Green/Purple

and also to the wire of the AXCSD-6V. Blue/White

• Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.

To allow an aftermarket camera to be added to the OEM screen:

• Connect the wire to the ground wire of the aftermarket camera.Black

• Connect the Yellow wire to battery wire of the aftermarket camera.

• Connect the female Yellow RCA jack to the aftermarket camera.

• The AXCSD-6V 12-volt to 6-volt converter will not be used in this application.
