Side 1/3
AXBUCH-SB2
INSTALLATION INSTRUCT I ON S
REV. 3/3/21
© COPYRIGHT 2021 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
HARNESS
TOOLS REQUIRED
• AXBUCH-SB2 harness
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
† Base models with a 6.2-inch screen
* It is highly recommended to use the (sold separately) AXCSD-6V
to provide the camera with the proper voltage
Visit axxessinterfaces.com for more detailed information
about the product and up-to-date vehicle specific applications
Subaru † Backup Camera Retention 2015-Up
APPLICATIONS
SUBARU*
Crosstrek 2016-2017
Forester 2017-2018
Impreza 2015-2016
WRX 2016-Up
WRX (w/ NAV) 2015
XV Crosstrek 2015
* All vehicles will require an AXCSD-6V 12V to 6V step down
AXBUCH-SB2
INSTALLATION INSTRUCT I ON S
REV. 3/3/21
© COPYRIGHT 2021 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
To retain the factory backup camera to an aftermarket radio, connect the:
wire to chassis ground.Black
wire from the Black AXCSD-6V to chassis ground.
wire to the wire from the Red Blue/Red AXCSD-6V.
wire from the Blue/White AXCSD-6V to accessory power.
Yellow
male
RCA jack to the backup camera input from the aftermarket radio.
Disregard the
female
Yellow RCA jack.
CONNECTIONS
