Installation instructions for part AXDI-GMLN11

REV. 1/20/2020 INSTAXDI-GMLN11

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse,

and speed sense)

• Retains chimes through an onboard speaker

• Pre-wired AXSWC harness (AXSWC sold

separately)

•

Designed for non-amplified models, amplified

models, or when bypassing a factory amplifier

• Retains balance and fade

• Micro “B” USB updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

APPLICATIONS

Connections to be made 2 ...................................................

Installing the AXDI-GMLN11 3 .............................................

Initializing the AXDI-GMLN11 3 ...........................................

Table of Contents

• AXDI-GMLN11 interface • AXDI-GMLN11 harness

INTERFACE COMPONENTS

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 2010

PONTIAC (CONT)

G6 (5th digit of VIN must

be a J, K, or L) 2009

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2007-2009

AXDI-GMLN11

Connections to be made

From the AXDI-GMLN11 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the accessory wire.Red

• Connect the wire to the amplifier turn on wire.Blue

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

12-pin pre-wired AXSWC harness:

• This harness is to be used along with the optional AXSWC (not included) to

retain steering wheel audio controls. If the AXSWC is not being used, disregard

this harness. If it will be used, please refer to the AXSWC instructions for radio

connections and programming.

Note: Disregard the harness that comes with the AXSWC.

• The following wire must be cut before programming the AXSWC:

• For the following vehicles cut the wire. If your vehicle is not Green/Orange

listed, do not cut anything:

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 2010

PONTIAC (CONT)

G6 (5th digit of VIN must

be a J, K, or L) 2009

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2006-2009
