AXDIS-GMLN29

I N S TA L L A T I O N I N S T R U C T I O N S

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape • Connectors (example: butt-connectors, bell caps, etc.) • Small ﬂat-blade screwdriver

TABLE OF CONTENTS

Connections ........................................................3-6

- For models

without

an ampliﬁer ....................... 3

- For models

with

an analog ampliﬁer ................4

- For models

with

a digital ampliﬁer ................... 5

- 3.5mm jack steering wheel control retention ...6

Installation .............................................................6

Programming ......................................................... 7

Adjustments ........................................................... 7

Extra features .........................................................8

Steering wheel control settings .......................9-11

- L.E.D. feedback ....................................................9

- Changing radio type ...........................................9

- Remapping the steering wheel control buttons ...10

- Dual assignment instructions (long button press) ...11

Troubleshooting ....................................................12

GM Data Interface with SWC 2006-Up

• Provides accessory power

(12-volt 10-amp)

• Retains R.A.P. (retained

accessory power)

• Provides NAV outputs (parking

brake, reverse, speed sense)

• Retains chimes

• Retains audio controls on the

steering wheel

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Retains the factory AUX-IN jack

•

Retains the factory backup camera

•

Retains RSE (rear seat entertainment)

• Retains SAT (satellite radio)

• Can be used in non-ampliﬁed, or

analog/digital ampliﬁed models

•

Retains balance and fade (excluding

digital ampliﬁed models)

• Includes an antenna adapter

• Micro-B USB updatable

• AXDIS-GMLN29 interface • AXDIS-GMLN29 harness

• 16-pin harness with stripped leads • 4-pin to 4-pin resistor pad harness

• Female 3.5mm connector with stripped leads

• Backup camera harness • RSE harness • Antenna adapter

APPLICATIONS

See inside front cover

APPLICATIONS

BUICK

Enclave 2008-2017

Lucerne 2006-2011

CADILLAC

DTS † 2006-2011

Escalade † 2007-2014

SRX † 2007-2009

CHEVROLET

Avalanche * 2007-2013∆

Captiva Sport 2012-2015

CHEVROLET (CONT)

Equinox 2007-2009

Express ‡ 2008-Up

Impala 2006-2013

Impala

Limited

2014-2016

Monte Carlo 2006-2007

Silverado 2500/3500 * 2014∆

Silverado (new body) * 2007-2013 ∆

Suburban ** 2007-2014∆

Tahoe ** 2007-2014∆

Traverse 2009-2017

GMC

Acadia 2007-2016

Acadia

Limited

2017

Savana ‡ 2008-Up

Sierra 2500/3500 * 2014∆

Sierra (new body) * 2007-2013∆

Yukon / Yukon XL ** 2007-2014∆

HUMMER

H2 † 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

Vue 2008-2010

SUZUKI

XL-7 2007-2009

* These vehicles have a digital amp option. Please reference the “Service Parts Identiﬁcation” sticker located in the glove box for the RPO code Y91. If Y91 is present, then

the vehicle is equipped with a digital ampliﬁer.

** These vehicles have a digital amp option. Please reference the “Service Parts Identiﬁcation” sticker located in the glove box for the RPO code STZ or Y91. If STZ or Y91 is

present, then the vehicle is equipped with a digital ampliﬁer.

† These vehicles are standard for a digital ampliﬁer.

‡ For 2013-2015 models equipped with NAV use the AXDIS-GMLN44.

∆ For 2012-up models equipped with NAV use the AXDIS-GMLN44.
