Side 1/12

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AXDIS-GMLN44

I N S TA L L A T I O N I N S T R U C T I O N S

INTERFACE FEATURES

INTERFACE COMPONENTS

TABLE OF CONTENTS

Connections to be made ................................... 3-6

- For models

without

an ampliﬁer .......................3

- For models

with

an analog ampliﬁer ................4

- For models

with

a digital ampliﬁer ...................5

- 3.5mm jack steering wheel control retention ..6

Installing the AXDIS-GMLN44 ................................6

Programming the AXDIS-GMLN44 ........................7

Adjusting the AXDIS-GMLN44 ...............................7

Steering wheel control settings ......................8-10

- L.E.D. feedback ....................................................8

- Changing radio type ...........................................8

- Remapping the steering wheel control buttons ..9

- Dual assignment instructions

(long button press) ............................................ 10

Troubleshooting .................................................... 11

GM Data Interface with SWC 2012-2016

• Provides accessory power

(12-volt 10-amp)

• Retains R.A.P. (retained

accessory power)

• Provides NAV outputs (parking

brake, reverse, speed sense)

• Retains chimes

• Retains audio controls on the

steering wheel

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Retains the factory AUX-IN jack

•

Can be used in non-ampliﬁed, or

analog/digital ampliﬁed models

• Retains balance and fade

(excluding digital ampliﬁed

models)

• Micro “B” USB updatable

• AXDIS-GMLN44 interface • AXDIS-GMLN44 harness

• 16-pin harness with stripped leads • 4-pin to 4-pin resistor pad harness

• Female 3.5mm connector with stripped leads

APPLICATIONS

See inside front cover

TOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape • Connectors (example: butt-connectors, bell caps, etc.) • Small ﬂat-blade screwdriver

APPLICATIONS

CHEVROLET

Avalanche † * 2012-2013

Express † 2013-2015

Malibu (with monochrome display) 2013-2015

Malibu Limited (with monochrome display) 2016-2016

Silverado 2500 / 3500 † * 2014

CHEVROLET (CONT)

Silverado † * 2012-2013

Suburban † ** 2012-2014

Tahoe † ** 2012-2014

Trax 2015-2016

GMC

Savana † 2013-2015

Sierra 2500 / 3500 † * 2014

Sierra † * 2012-2013

Yukon / Yukon XL † ** 2012-2014

* These vehicles have a digital amp option. Please reference the “Service Parts Identiﬁcation” sticker located in the glove box for the RPO code Y91. If Y91 is present, then the vehicle is equipped with

a digital ampliﬁer.

** These vehicles have a digital amp option. Please reference the “Service Parts Identiﬁcation” sticker located in the glove box for the RPO codes; Y91, STZ, UQS. If Y91, STZ or UQS is present, then the

vehicle is equipped with a digital ampliﬁer.

† Only for models with NAV.
