AXDSPL-GM31

I N S T A L L A T I O N I N S T R U C T I O N S

Google Play Store Apple App Store

iOS 12.1 or higher

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties • Multimeter

TABLE OF CONTENTS

Installation Options ...............................................2

Installation .............................................................2

Connections ........................................................3-4

AXDSPL-BT Installation...........................................5

AXDSPL-SP Installation...........................................6

Mobile App .........................................................7-15

Speciﬁcations ....................................................... 16

GM DSP Interface With Pre-Wired Harness

2019-Up

• Includes a DSP (Digital Signal Processor)

• 15 Band graphic EQ

• 4 inputs and 6 individually assignable outputs

• Independent equalization for front, rear, and sub

• Selectable low pass, band pass, and high pass ﬁlters

• Selectable crossover slopes; 12db, 24db, 36db, 48db

• Each channel can be delayed independently up to 10ms

• Clipping detection and limiting circuits

• Retains factory parking sensor chimes

• Retains OnStar® voice prompts

• Adjustable chime level

• Designed for non-ampliﬁed models

• Easy behind the radio installation with pre-wired harness

• Internal header port for adding interface modules

• Bass knob included for level control of subwoofer amp

• Settings adjusted via Bluetooth® in a smart device application (tablet

or mobile phone), compatible with both Android and Apple devices

• Read, write, and store conﬁgurations for future recall

• Password protect feature available in the mobile app

• Micro-B USB updatable

• AXDSPL-GM31 interface

• AXDSPL-GM31 interface harness

• AXDSPL-GM31 vehicle T-harness • Bass knob

APPLICATIONS

Visit axxessinterfaces.com for current application list

Adding a sub to a factory system:

This feature offers the ability to add a subwoofer to a factory system. (refer to page 3)

Adding a full-range amp & sub to a factory system:

This feature offers the ability to add a full-range amp and sub to a factory system. (refer to page 4)

16-pin header port:

Inside the interface is a 16-pin header port for adding optional modules (sold separately). Page 5

and 6 will show the installation and use of these modules.

• AXDSPL-BT - Bluetooth streaming interface

• AXDSPL-SP - Toslink digital output

Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing

multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps

combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.

1. Remove the factory radio †, then unplug all connectors.

2. Install the AXDSPL-GM31 vehicle T-harness to the vehicle and make all necessary

connections, but leave the amp turn-on wire disconnected.

3. AXDSPL-GM31 vehicle T-harness AXDSPL-GM31 interface Plug the to the .

4. Plug the AXDSPL-GM31 interface harness AXDSPL-GM31 interface to the .

Download and install the AX-DSP-X app Google Play Store Apple App Store from the or

Cycle the ignition on.

7. Open the app then select the Bluetooth Connection tab. Follow the instructions to

pair the mobile device to the interface. Refer to page 6 for more information.

8. Conﬁguration Scroll to the tab then select the vehicle type. Press the ‡ Lock Down

button to save the conﬁguration. Refer to page 7 for more information.

9. Connect the amp turn-on wire.

10. Adjust the settings in the app as desired. Press the ‡ button to save any Lock Down

new conﬁgurations.

† Refer to Metra online for dash disassembly. If Metra makes a dash kit for the vehicle,

disassembly will be within those instructions.

‡ Anytime the interface is locked down the key must be cycled off then back on

INSTALLATION OPTIONS INSTALLATION
