Side 1/8

AXDSPL-HK2

INSTALLATION INSTRUCTIONS

Google Play Store

Apple App Store

iOS 12.1 or higher

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties • Multimeter

TABLE OF CONTENTS

Connections ............................................................2

Installation .............................................................3

AXDSPL-BT Installation...........................................4

AXDSPL-SP Installation...........................................5

Mobile App...........................................................6-7

Specifications /Speaker Assignment QR code.....8

Hyundai/Kia DSP Interface With Amp Bypass

Harness

2011-2016

• Includes a DSP (Digital Signal Processor)

• 15 Band graphic EQ

• 4 inputs and 6 individually assignable outputs

• Independent equalization for front, rear, and sub

• Selectable low pass, band pass, and high pass filters

• Selectable crossover slopes; 12db, 24db, 36db, 48db

• Each channel can be delayed independently up to 10ms

• Clipping detection and limiting circuits

• Retains BlueLink/UVO voice prompts, with adjustable level

• Designed for SPDIF amplified models

• Includes an amp bypass harness

• Internal header port for adding interface modules

• Bass knob included for level control of subwoofer amp

• Settings adjusted via Bluetooth

in a smart device application (tablet

or mobile phone), compatible with both Android and Apple devices

• Read, write, and store configurations for future recall

• Password protect feature available in the mobile app

• Micro-B USB updatable

• AXDSPL-HK2 interface

• LD-DSP-HYKIA2 interface harness

• AXDSPL-HK2 amp bypass harness

• AXBK-1 (bass knob)

APPLICATIONS

Visit

AxxessInterfaces.com

for current application list

www.MetraOnline.com

MetraOnline.com may be used to assist with

dash assembly instructions. Simply enter your

Year, Make, Model vehicle into the vehicle fit

guide and look for the Dash Kit Installation

Instructions.

TBA

Blue/White - Amp Turn-On Wire

Interface

Any remaining wires

tape off and disregard

RCA Jacks

(sold separately)

Amp Bypass Harness

BONK SSAB

Any remaining wires

tape off and disregard

TBA

Factory Amp

An SPDT relay, Metra part number

E-123, is required if the amp turn-on

current of all amps exceeds 1-amp.

Please see Speaker Assignment

QR Code located on page 7 of

instructions

CONNECTIONS

LD-DSP-HYKIA2

LD-DSP-LT-OUT
