AXDSPX-MI1

INSTALLATION INSTRUCTIONS

Google Play Store

Apple App Store

iOS 12.1 or higher

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip-ties • Multimeter

TABLE OF CONTENTS

Installation Options ...............................................2

Installation .............................................................2

Connections ........................................................3-4

Mobile App ........................................................5-14

Speciﬁcations ........................................................15

Mitsubishi DSPX Interface w/ Pre-Wired

Harness

(for non-ampliﬁed vehicles)

1993-2012

• Includes a DSP (Digital Signal Processor)

• Selectable 31 Band Graphic EQ or 5 Band Parametric EQ

• 10 individually assignable outputs

• Independent equalization on each of the 10 outputs

• Independent high pass, low pass, and bandpass ﬁlters

• Each channel can be delayed independently up to 10ms

• Clipping detection and limiting circuits

• Designed for non-ampliﬁed models

• Easy behind the radio installation with pre-wired harness

• Bass knob included for level control of subwoofer amp

•

Settings adjusted via Bluetooth® in a smart device application (tablet

or mobile phone), compatible with both Android and Apple devices

• Read, write, and store conﬁgurations for future recall

• Password protect feature available in the mobile app

• USB Micro B updatable

• AXDSPX-MI1 interface

• AXDSPX-MI1 interface harness

• AXDSPX-MI1 vehicle T-harness • Bass knob

• AXDSPX-MI1 display T-harness

APPLICATIONS

Visit axxessinterfaces.com for current application list

Adding a subwoofer to a factory system:

The diagram on Page 3 shows the connections that need to be made to add a subwoofer to the

factory system.

Note: RCA jacks sold separately.)

Adding a full-range of amps & subwoofer to a factory system:

The diagram on Page 4 shows the connections that need to be made to add: Subwoofer (RCA jacks

sold separately)

Ampliﬁer (SPDT relay E-123 required) or

Additional Amp (RCA jacks sold separately).

Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing

multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps

combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.

1. Disassemble the dash, unplug all connectors, and then remove the factory radio. †

2. Install the AX-DSPX-MI1 vehicle T-harness to the vehicle and make all necessary

connections, but leave the amp turn-on wire disconnected.

3. Plug the AX-DSPX-MI1 vehicle T-harness to the AX-DSPX-MI1 interface.

4. Plug the AX-DSPX-MI1 interface harness to the AX-DSPX-MI1 interface.

5. Download and install the AX-DSP-XL app from the Google Play Store or Apple App Store.

6. Open the app then select the Bluetooth Connection tab. Follow the instructions to

pair the mobile device to the interface. Refer to page 6 for more information.

7. Scroll to the Conﬁguration tab then select the vehicle type. Press the Lock Down ‡

button to save the conﬁguration. Refer to page 7 for more information.

8. Connect the amp turn-on wire.

9. Adjust the settings in the app as desired. Press the Lock Down ‡ button to save any

new conﬁgurations.

† For dash disassembly instructions, refer to metraonline.com. Enter the year, make,

and model of the vehicle in the Vehicle Fit Guide and ﬁnd instructions under Metra

Radio Install kits.

‡ Anytime the interface is locked down the key must be cycled off then back on.

INSTALLATION OPTIONS I N STALL AT I O N
