Installation instructions for part AXGM-08

REV. 1/20/2020 INSTAXGM-08

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

•

Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes

• Pre-wired AXSWC harness (AXSWC sold

separately)

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for amplified models

• Retains balance and fade

• AXUSB-CBL (sold separately) updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

AXGM-08

GM Data Interface

2005-2006

APPLICATIONS

• AXGM-08 interface • AXGM-08 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made .........................................2

Installing the AXGM-08 ..........................................3

Initializing the AXGM-08 ........................................3

Adjusting the AXGM-08 ..........................................3

Table of Contents

CHEVROLET

Equinox 2005-2006

PONTIAC

Torrent 2006

AXGM-08

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

Note: If installing an AXSWC (sold separately), there will be an accessory wire

there to connect as well.

• Connect the wire to the amp turn on wire. This wire must be Blue/White

connected to hear sound from the factory amplifier.

• If the aftermarket radio has an illumination wire, connect the Orange/White

wire to it.

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

From the AXGM-08 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

12-pin pre-wired AXSWC harness:

• This harness is to be used along with the optional AXSWC (not included) to

retain steering wheel audio controls. If the AXSWC is not being used, disregard

this harness. If it will be used, please refer to the AXSWC instructions for radio

connections and programming.

Note: Disregard the harness that comes with the AXSWC.

• Connect the wire to the accessory wire.Red

Connections to be made
