Installation instructions for part AXGM-09

REV. 1/20/2020 INSTAXGM-09

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

•

Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for amplified models

• Retains balance and fade

• AXUSB-CBL (sold separately) updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

AXGM-09

GM Data Interface

2001-2005

• AXGM-09 interface • AXGM-09 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made .........................................2

Installing the AXGM-09 ..........................................3

Initializing the AXGM-09 ........................................3

Adjusting the AXGM-09 ..........................................3

Table of Contents

APPLICATIONS

OLDSMOBILE

Aurora 2001-2003

PONTIAC

Bonneville 2000-2005

AXGM-09

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

• Connect the wire to the amp turn on wire. This wire must be Blue/White

connected to hear sound from the factory amplifier.

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wireLight Green

• Tape off and disregard the following (1) wire, it will not be used in this

application: .Orange/White

From the AXGM-09 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the power antenna wire.Blue

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

• Cut and tape off the appropriate wire on the 32-pin harness:Blue/White

• For model years 2000-2001 cut pin-A6.

• For model years 2002-2005 cut pin-A3.

Connections to be made
