Installation instructions for part AXGMLN-01

REV. 8/6/2020 INSTAXGMLN-01

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Pre-wired AXSWC harness (AXSWC sold

separately)

• Retains chimes to the factory speaker

• Adjustable chime level

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Retains the factory backup camera

• Designed for non-amplified models, or

when bypassing a factory amp

• Retains balance and fade

• Includes an antenna adapter

• AXUSB-CBL updatable (sold separately)

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

AXGMLN-01

GM Data Interface

2006-Up

• AXGMLN-01 interface • AXGMLN-01 harness

• 16-pin harness with stripped leads • Backup camera harness • Antenna adapter

INTERFACE COMPONENTS

Connections to be made 2-3 ................................................

Installing the AXGMLN-01 3 ................................................

Initializing the AXGMLN-01 3 ..............................................

Adjusting the AXGMLN-01 4 ................................................

Table of Contents

APPLICATIONS

See inside front cover

AXGMLN-01

Applications

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

Note: If installing an AXSWC (sold separately), there will be an accessory wire

there to connect as well.

• If the aftermarket radio has an illumination wire, connect the Orange/White

wire to it.

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

The following (3) wires are only for multimedia/navigation radios that require these wires

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

Connections to be made

† These vehicles are standard for a factory amplifier. Either use the AXGMLN-02 interface,

or bypass the amplifier.

‡ Only for models without NAV in 2011-2015. For models with NAV, use the AXGMLN-08.

∆ Only for models without NAV in 2012-up. For models with NAV, use the AXGMLN-08.

BUICK

Enclave 2008-up

Lucerne 2006-2011

CADILLAC

DTS † 2006-2011

Escalade † 2007-2014

SRX † 2007-2009

CHEVROLET

Avalanche ∆ 2007-2013

Captiva Sport 2012-2015

Equinox 2007-2009

Express ‡ 2008-up

Impala 2006-2013

Impala Limited 2014-2016

Monte Carlo 2006-2007

Silverado (new body) ∆ 2007-2013

Silverado 2500/3500 ∆ 2014

Suburban ∆ 2007-2014

Tahoe ∆ 2007-2014

Traverse 2009-up

GMC

Acadia 2007-2016

Acadia Limited 2017

Savana ‡ 2008-up

Sierra 2500/3500 ∆ 2014

Sierra (new body) ∆ 2007-2013

Yukon / Yukon XL ∆ 2007-2014

HUMMER

H2 † 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

Vue 2008-2010

SUZUKI

XL-7 2007-2009
