Side 1/3

AXLOC4-80A

INSTALL ATION INSTR UCTIONS

Integrate • AxxessInterfaces.com

Wire Color & Function: The audio and power input wire colors are an EIA standard for

car stereo applications as follows.

Note: Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXLOC4-80A. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and low quality audio.

Adjusting the AXLOC4-80A for maximum performance:

After completing all of the necessary connections, turn the AXLOC4-80A adjustment pots all of

the way down by rotating them completely counter-clockwise. Now, turn the stereo system on

and adjust the main volume control on the stereo to approximately 3/4 maximum volume. Select

one of the adjustment pots on the AXLOC4-80A and turn it slowly clockwise until you notice audio

distortion and then stop. Turn the remaining pot to the same position as the previously adjusted

pot. The audio set-up of the AXLOC4-80A is now complete and ready to be enjoyed.

INPUT HARNESS

White =

LEFT Front (+) Input

White/Black =

LEFT Front (-) Input

Gray =

RIGHT Front (+) Input

Gray/Black =

RIGHT Front (-) Input

Green =

LEFT Rear (+) Input

Green/Black =

LEFT Rear (-) Input

Purple =

RIGHT Rear (+) Input

Purple/Black =

RIGHT Rear (-) Input

Black = Reference Ground (-)

(Reference ground optional if noise is present)

AXLOC4-80A

INSTALL ATION INSTR UCTIONS

Integrate • AxxessInterfaces.com

4 Channel, Adjustable Line-Output Converter

The AXLOC4-80A is designed to convert 4 channels of speaker level audio to

line level audio. This allows for the installation of line level products such as

ampliﬁers, EQs and crossovers on radio’s that do not have RCA line level outputs.

Features:

80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly

Found On Other Brands of LOCs, 6:1 Step Down with Variable Output, Detachable

Input Plug, Gold Flashed RCAs, Attractive & Durable Enclosure.
