AXLOC4M-150
INSTALL ATIO N I NSTRUCTI O NS
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifier Remote Generator.
The LOC is designed to convert (4) channels of speaker level audio into (4) channels of line
level audio that can be used by OEM amplifiers. It can also be used with OEM radios to add
aftermarket amplifiers. This device will also detect the presence of an audio signal and then
generate a +12V output that can be used to turn-on an aftermarket amplifier.
Features and specifications
The LOC is able to handle 150 watts per channel continuous input without over heating.
The input circuitry is designed to correct the crossover distortion commonly found on
standard LOCs while providing a high to low level step down of 6:1. Output audio level is
infinitely adjustable using the onboard, high quality potentiometers. The remote output
or amplifier trigger is rated at 500mA (+12V) and will easily handle an outboard relay if
additional current is needed. The remote output will trigger instantaneously when the LOC
detects a DC voltage on the white, left + audio input wire above 5V or a very low audio
signal. It will shut off 60 seconds after no signal is detected.
Installation
The LOC should be installed on a stereo’s speaker output wires or the output wires on an
OEM amplifier of up to 150 watts per channel. These wires can be found behind the stereo
in the dash, on the output of an OEM amplifier, or on the input terminals on the OEM
speakers. Please refer to the wiring diagram for the input connection details.
Continued on next page
AXLOC4M-150
INSTALL ATIO N I NSTRUCTI O NS
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Wire color and function
The audio and power input wire colors are an EIA standard for car stereo applications as follows:
Input harness
White = left front (+) input
White/Black = left front (-) input
Gray = right front + input
Gray/Black = right front (-) input
Green = left rear (+) input
Green/Black = left rear (-) input
Purple = right rear (+) input
Purple/Black = right rear (-) input
Power harness
Yellow = battery +12v input
Black = power (-) ground input
Blue = remote +12v output
Brown = reference ground (-)
Note:
Be sure that all audio input connections are polarized or in phase with each other. Failure to do this will result in
poor bass response and low quality audio.
Adjusting the LOC for maximum performance: After completing all of the necessary connections, turn the LOC adjustment
pots all of the way down by rotating them completely counter-clockwise. Now, turn the stereo system on and adjust the
main volume control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment pots on the LOC
and turn it slowly clockwise until you notice audio distortion and then stop. Turn the remaining pots to the same position as
the previously adjusted pot. The audio set-up of the LOC is now complete and ready to be enjoyed.
K PNOWLEDGE IS OWER
Enhance your inst allat ion and fa bricat ion skills by
enrolling in t he most recogniz ed and spect ed re
mobile elect nics scho ol in our indust ry.ro
Log ont o www.installerinstit ute.com or ca ll
800-3 54-6782 for mo informat ion a nd take steps re
to ward a bet ter tomorrow.
®
Metra recommends MECP
certified technicians
IMPORTANT
If you are having difficulties with the installation of this product,
please call our Tech Support line at 1-800-253-TECH. Before doing
so, look over the instructions a second time, and make sure the
installation was performed exactly as the instructions are stated.
Please have the vehicle apart and ready to perform troubleshooting
steps before calling.
