AXLOCM-150
INSTALL ATIO N I NSTRUCTI O NS
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The Line Output Converter (LOC) should be installed on a stereo’s speaker output wires or the output
wires on an OEM amplifier of up to 75 watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplifier, or on the input terminals on the OEM speakers.
Wire color and function
The audio input wire colors are an EIA standard for car stereo applications as follows:
Yellow Battery +12v input
Black Ground input
Blue Remote +12v output the above power wires can be connected directly
to the amplifier being added
White Left front (+) input
White/Black Left front (-) input
Gray Right front (+) input
Gray/Black Right front (-) input
Black/White Reference ground (-) (reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with each other. That is, the
positive output wires from the audio source need to be connected to the corresponding positive
input wires of the LOC. The same goes for the negative audio wires. Failure to do this will result in
poor bass response and low quality audio.
Continued on other side
2 Channel Line Output Converter (LOC) with Amp Turn-On
AXLOCM-150
INSTALL ATIO N I NSTRUCTI O NS
REV. 12/13/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The LOC is designed to convert (2) channels of speaker level audio into (2)
channels of line level audio. This allows for the installation of line level products
such as amplifiers, EQs and crossovers on systems that do not have RCA line level
outputs. In addition this device will also detect the presence of an audio signal and
then generate a +12V output that can be used to turn-on an aftermarket amplifier.
Features
75 watts maximum input
Input circuit corrects
Crossover distortion commonly found on other brands of LOCs
6:1 Step down with variable output
Gold flashed RCAs
Attractive and durable enclosure
Note: The LOC will shut off 60 seconds after no signal detected.
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
K PNOWLEDGE IS OWER
Enhance your inst allation and fab rication skills by
enrolling in the most cogniz ed and spected re re
mobile elec tronics s chool in our indust ry.
Log ont o www.installerinst itute.com or call
800-354-6 782 for mo informat ion and take ste ps re
tow ard a bett er tomo rrow.
Metra recommends MECP
certified technicians
