AXPIO-SIL1
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 7/30/24 INSTAXPIO-SIL1
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
TABLE OF CONTENTS
Speaker Installation...............................................2
Dash Disassembly 2-3 ..............................................
Kit Preparation 4 .......................................................
Connections 5-6 ........................................................
Kit Assembly 7 ..........................................................
Radio Operations 8-9 ...............................................
Chevrolet GMC Silverado/ Sierra 2014-2019 (excluding 2019 WT Trim)
with RPO (I05/I06/I0B)
KIT FEATURES)
• Designed for Pioneer DMH-W4600NEX/W4660NEX or DMH-WC5700NEX receivers
• Allows for the retention and adjustment of the factory personalization menu
through the Pioneer radio
• Provides a visual view of HVAC and gauges on the Pioneer screen (cannot be
adjusted via the screen) (cont. on page 2)
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Phillips screws 9/32" (4)
Not Shown: Radio Interface, LD-GMLAN09-PIO, LD-GMLAN10-PIO, AXEXH-GM09, AXEXH-GM10, LD-BACKCAM-MOST, LD-GMSWC, AD-EU5, 40-GPS-PIO, PR04AVIC-PIO /
PRO4-PIORCA, LD-AX-SPK, AXUSB-GM6
Visit for more detailed information about the product and up-to-date AxxessInterfaces.com
vehicle specific applications.
WIRING & ANTENNA CONNECTIONS (sold separately)
•
RGB Extension Cable: Pioneer part # CD-RGB150A
(not sold by Metra)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32" socket wrench
A B C
