Installation instructions for part AXRC-GM3

REV. 2/4/2020 INSTAXRC-GM3

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and speed sense)

• Used in non-amplified models, or when bypassing a factory amplifier

• Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

INTERFACE FEATURES

• Cutting tool • Crimping tool • Tape • Connectors

(example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

AXRC-GM3

Cadillac Data Interface

1996-2005

APPLICATIONS

• AXRC-GM3 interface • 32-pin Cadillac harness

INTERFACE COMPONENTS

CADILLAC

Catera 1997-2001

Deville 1996-1999

Deville* 2000-2005

Eldorado 1996-2002

Seville 1996-1997

Seville* 1998-2004

*Note: You must bypass the factory amp in

these vehicles to use this interface.

Connections to be made ........................................ 2

Installing the Axxess Interface 3 .............................

Initializing the Axxess Interface 3 ...........................

Table of Contents

AXRC-GM3

From the AXRC-GM3 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the accessory wire.Red

• Connect the wire to the power antenna wire.Blue

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these

wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

Connections to be made
