Installation instructions for part AXRC-GM5

REV. 1/21/2020 INSTAXRC-GM5

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

Connections to be made ............................................2

Installing the AXRC-GM5 ...........................................3

Initializing the AXRC-GM5 .........................................3

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse,

and speed sense)

• Used in both amplified and non-amplified sound

systems

• Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

AXRC-GM5

GM Data Bus Interface

2005-2006

APPLICATIONS

• AXRC-GM5 interface • AXRC-GM5 harness

INTERFACE COMPONENTS

Table of Contents

CHEVROLET

Equinox 2005-2006

OLDSMOBILE

Torrent 2006

AXRC-GM5

Connections to be made

From the AXRC-GM5 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the accessory wire.Red

• Connect the wire to the amp turn-on wire.Blue/White

• If the aftermarket radio has an illumination wire, connect the Orange

wire to it.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that

require these wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green
