AXRSEH-G2
INSTALL ATION INSTRUCTI O NS
REV. 4/20/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
• Retains the A/V-IN jack (if applicable)
• Provides A/V output to the factory installed rear seat overhead
entertainment system *
Designed for models that have a DVD player built into the factory radio
INTERFACE FEATURES
• Wire cutter • Crimping tool
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
GM
(with NAV)
RSE A/V Harness 2012-2014
APPLICATIONS
• AXRSEH-G2 harness
Connect to the AXRSEH-G2 harness to the wiring harness in the
vehicle located at the radio location.
INTERFACE COMPONENTS
CONNECTIONS TO BE MADE
INSTALLATION
* Only applicable for models with a second row RSE
Connect the wire with a ring terminal to the chassis of the aftermarket radioBlack
.
From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the
aftermarket radio:
• Connect the Yellow RCA jack to the video in.
• Connect the and RCA jacks to the audio in.Red White
From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the
aftermarket radio:
• Connect the Yellow RCA jack to the video out.
• Connect the and RCA jacks to the audio out.Red White
CADILLAC
Escalade 2012-2014
CHEVROLET
Avalanche 2012-2013
Silverado 2500/3500 2014
Silverado 2012-2013
CHEVROLET (CONT)
Suburban 2012-2014
Tahoe 2012-2014
GMC
Sierra 2500/3500 2014
Sierra 2012-2013
Yukon 2012-2014
