AXSSO-CH3
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 9/6/23 INSTAXSSO-CH3
INTERFACE FEATURES
INTRODUCTION
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Zip ties • Cutters (for zip-ties)
• Micro-B USB Cable
(Axxess part number )AXUSB-MCBL
TABLE OF CONTENTS
Programming 2 .........................................................
Connections 3 ............................................................
Operation................................................................3
Dodge/Jeep Stop/Start Override Interface
2020-2021
APPLICATIONS
• Allows the override of the STOP/START engine feature
• The factory STOP/START button can resume the STOP/START feature
• Can be used with either a factory or aftermarket radio
•
Vehicle type configured through the Axxess Updater software program
• Simple plug n’ play installation, no wiring required
The AXSSO-CH3 is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been
cycled. The AXSSO-CH3 will work with either an aftermarket radio, or a factory radio. A simple plug n’ play installation is all that is required to
install the device in the vehicle, and programming through a Windows 10 computer via the software program.
Axxess Updater
Dodge
Durango 2020-2021 ...........................................
Jeep
Cherokee..........................................2020-2021
Grand Cherokee 2020-2021 ..............................
• AXSSO-CH3 interface
• AXSSO-CH3 harness
Visit for current application list
Axxessinterfaces.com
Visit for more detailed information about MetraOnline.com
the product and up-to-date vehicle specific applications.
Product Info
ATTENTION:
With the key out of the
ignition, disconnect the negative battery
terminal before installing this product.
Ensure that all installation connections,
especially the air bag indicator lights, are
plugged in before reconnecting the battery
or cycling the ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
2
PROGRAMMING
(Figure A) (Figure B) (Figure C)
1.
2.
3.
4.
Download and install the software program from: Axxess Updater
axxessinterfaces.com/resources/updater-software
On the next screen that opens, select the year, make, and model of the
vehicle, then press . (Figure B)Program Interface
Connect the micro-B USB cable (sold separately) to the computer and
AXSSO-CH3 interface. Open the software program and Axxess Updater
wait until the word is shown in the bottom left of the screen. Ready
Select . (Figure A)Stop / Start
When the box pops up, the programming Configuration Successful
process is complete. (Figure C)
Continue to Installation
