Side 1/4

AXSSO-GM

I N S T A L L A T I O N I N S T R U C T I O N S

Patent #10844821, 11459994, 11493012

Product Info

INTERFACE FEATURES

INTRODUCTION

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Zip ties • Zip tie cutter

• GM battery terminal wrench

TABLE OF CONTENTS

Installation .............................................................2

GM Stop/Start Override Interface 2016-2019

• Allows the override of the STOP/START engine feature

• Can be used with either a factory or aftermarket radio

• No programming required

• Simple 2-wire setup

The AXSSO-GM is designed to disengage the STOP/START feature of the vehicle, and

keep that feature disengaged even after the key has been cycled. The AXSSO-GM

will work with either an aftermarket or a factory radio. Simple 2-wire installation

(ground and power to the battery) is all that is required to install the interface in

the vehicle. No programming required!

• AXSSO-GM interface

• LD-GM1-SSO harness

• LD-GM2-SSO harness

APPLICATIONS

Buick

Enclave 2018

Encore 2016-2018

Envision 2016-2019

LaCrosse 2017-2019

Regal 2017-2018

Cadillac

CTS 2019

XT5 2017-2018

Chevrolet

Cruze 2017-2018

Equinox 2018-2019

Malibu 2016-2017

Chevrolet (Cont)

Traverse 2018

Trax 2016-2018

GMC

Acadia 2017-2018

Terrain 2018-2019

Yukon 2018

Buick

Enclave 2019

Encore 2019

Regal 2019

Cadillac

CT6 2019

Escalade 2019

Cadillac (Cont)

XT4 2019

XT5 2019

XTS 2019

Chevrolet

Corvette 2019

Cruze 2019

Chevrolet (Cont)

Silverado 2019

Tahoe 2019

Traverse 2019

Trax 2019

GMC

Acadia 2019

LD-GM1-SSO applications LD-GM2-SSO applications

INSTALLATION

(Figure shown for illustration purposes only. Actual vehicle and installation locations will differ)

1. Open the hood and locate the hood pin switch

harness underneath the hood latch.

2. Unplug the hood pin switch harness, then plug in

the appropriate harness.

3. Route the power and ground wires to the vehicles

battery.

4. Connect the wire to the negative terminal.Black

5. Yellow Connect wire to the positive terminal.

6. Find a safe and secure spot for the water resistant

AXSSO-GM interface, away from any heat sources

and moving parts. With the wiring harness facing

downward, zip tie the interface securely.

7. The installation is now complete.

There are 2 T-harnesses to choose from.Note:

Tape up and disregard the Note: White/Green

and wires from the interface.White/Red

Tech Tip! After install, if the check engine light

appears, remove ground connection that was

made to the battery and splice into the Brown

wire on the vehicle side of the T-harness.
