Side 1/5
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/20/20
Installation Instructions for AXSWCH-T28
FEATURES
• Plug and play harness for the AXSWC (sold separately)
• Retains the factory AUX-IN jack
INTERFACE COMPONENTS
• AXSWCH-T28 harness
AXSWCH-T28
Plug and Play Harness for the AXSWC
(sold separately) 2012-up
SCION
tC 2014-2015
SUBARU
Forester (w/ nav)
2014-2015
Forester (w/ SD based nav)
2012-2013
Impreza WRX (w/ nav)
2013-2014
Legacy 2015
Legacy (w/ HK amp)
2012-2013
Outback 2015
Outback (w/ HK amp)
2012-2013
WRX (w/ nav) 2015
XV Crosstrek (w/ nav)
2013-2014
LEXUS
CT 200h 2011-2015
TOYOTA
4-Runner 2013-2015
Avalon 2013-2015
Camry 2012-2015
Corolla 2013-2015
Corolla (w/ nav) 2011-2015
FJ Cruiser (w/ nav) 2013
Highlander 2013-2015
Matrix (w/ USB) 2013
Prius V 2012-2015
Prius C 2012-2015
Prius 2012-2015
Rav-4 2012-2015
Sequoia (w/ nav)
2013-2015
Tacoma 2013-2015
Tundra 2014-2015
Venza 2013-2015
Yaris Hatchback
2012-2015
• Cutting tool • Crimping tool • Tape • Connectors (example:
butt-connectors, bell caps, etc.)
TOOLS REQUIRED
APPLICATIONS
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/20/20
Installation Instructions for AXSWCH-T28
Connections to be made
From the AXSWCH-T28 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the wire to the accessory wire.Red
• Connect the and RCA jacks to the audio AUX-IN jacks (if so equipped).Red White
The following (2) wires are for aftermarket multimedia/navigation radios that provide these
wires (if not required, tape them off and disregard them):
• Connect the wire to the parking brake wire (if applicable).Light Green
• Connect the wire to the reverse wire (if applicable).Green/Purple
Installing the AXSWCH-T28
• With the key in the off position, connect the AXSWCH-T28 harness into the AXSWC (sold
separately), and then into the vehicle.
•
Follow the instructions included with the AXSWC (sold separately) for connections to the 3.5mm jack
.
• With all connections completed, reconnect the negative battery terminal.
Programming the AXSWC (sold separately)
When using the AXSWC to retain steering wheel audio controls:
• Turn the key to ignition; the L.E.D. in the AXSWC (sold separately) will flash fast.
Note: If your vehicle has a RETURN button on the steering wheel, press and hold that button
during this process.
• After about 20 seconds the L.E.D. will light up solid indicating the AXSWC (sold separately) has
been programmed. If the L.E.D. does not light up solid, or the steering wheel controls do not
work, refer to the instructions included with the AXSWC (sold separately) for troubleshooting.
IMPORTANT WARNING
This product includes instructions for installation which must be carefully followed. The
instructions are worded in such a manner to assume that the installer is capable of completing
these type of electronic installations. If you are unclear as to what you are instructed to do or
believe that you do not understand the instructions so as to properly and safely complete the insta
llation you should consult a technician who does have thisknowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described could cause
harm to the vehicle or to safety systems on the vehicle. Interference with certain safety systems
could cause harm to persons as well. If you have any questions in this regard please call the Help
line or Metra at 1-800-221-0932 for assistance.
