AXTC-LN31

I N S T A L L A T I O N I N S T R U C T I O N S

Visit for more detailed information AxxessInterfaces.com

about the product and up-to-date vehicle specific applications

ATTENTION:

With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights, are

plugged in before reconnecting the battery or cycling

the ignition to test this product.

NOTE:

Refer also to the instructions included with the

aftermarket accessory before installing this device.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections 2 ............................................................

Programming 3 .........................................................

Troubleshooting.....................................................4

GM Data Interface with SWC 2019-Up

APPLICATIONS

• Provides retained accessory

power (10-amp)

• Provides illumination, parking

brake, reverse, and speed

sense outputs

• Retains warning chimes

through an onboard speaker

• Retains the factory backup

camera

• Retains audio controls on the

steering wheel

• Designed to be compatible

with all major radio brands

• Auto detects vehicle type, radio

connection, and preset controls

• Ability to dual assign steering

wheel control buttons

• Retains memory settings even

after battery disconnection or

interface removal (non volatile

memory)

• Designed for non-amplified

models, or when bypassing a

factory amplifier

• Retains balance and fade

• Micro-B USB updatable

Chevrolet

Camaro ** 2019-Up(1) ................

Cheyenne ** 2019-2021(2) .........

Colorado 2019-Up(1) ..................

Cruze 2019 ....................................

Equinox ** 2019-Up(1) ...............

Malibu ** 2019-Up(1) ..................

Chevrolet (Cont)

Silverado ** 2019-2021(1) ..........

Sonic...............................2019-Up

Spark 2019-Up ..............................

GMC

Canyon 2019-Up(1) .....................

Sierra 1500 **........2019-2021(1)

Terrain ** 2019-Up(1) .................

• AXTC-LN31 interface

• AXTC-LN31 harness

• 3.5mm adapter

(1) IOR code radio †

** For extension, use AXEXH-GM31

† The radio code can be found in the Service Parts Identification Label located:

Glove box – Equinox/Terrain

QR only (see note) - Camaro/Canyon/Colorado/Malibu/Sierra/Silverado

Note: Newer model GM vehicles are transitioning to a QR style label. If the Ser-

vice Parts Identification Label is not located where listed, reference the Vehicle

Certification Label on the inside of the driver’s door opening for the QR code.

CONNECTIONS

Front

Rear

Sub

AUX-IN

Rear ewVi

SWC

Yellow RCA - Rear View

3.5mm Adapter (for vehicles without

Steering wheel controls or aftermarket

radios with a wire for SWC)

Boss (with C wire):SW y 1 - Br nKe (Gray) ow

Kenwood / JVC (with SWC wire): Blue/Yellow - Br now

XITE: 2 - Br nSWC- ow

Key-A or 1 - Br n SWC- ow

Key-B or 2 - Br n/WhiteSWC- ow

* After programming, assign C buttons within dio menuSW ra

Universal

Radio*

{

1) 3.5mm adapter Br n Br From the , tie the ow and own/White wires together with tape or connector

2) 3.5mm adapter -LN31 HarnessConnect the to the 3.5mm jack from the AXTC

3) Program the per the instructions on page 3. DisregarAXTC-LN31 d steps 4 & 5

3.5mm Adapter for Vehicles without Steering wheel controls

Radio Connections

Black - Ground

Yellow - Battery power

Red - Accessory power

Orange - Illumination

Blue/White- Amp turn-on

Blue/Pink - VSS/Speed-Sense

Green/Purple - Reverse signal

Light Green - Parking brake

Gray - Front right speaker +

Gray/Black - Front right speaker -

White - Front left speaker +

White/Black - Front left speaker -

Green - Rear left speaker +

Green/Black - Rear left speaker -

Purple - Rear right speaker +

Purple/Black - Rear right speaker -

Aftermarket Radio

(radio’s features may vary)

Reset Button

LED

Vehicle

Connector

Produkt Specifikationer

Mærke:	AXESS
Kategori:	Ikke kategoriseret
Model:	AXTC-LN31
