AXTO-TY1

I N S TA L L A T I O N I N S T R U C T I O N S

ATTENTION: With the key out of the

ignition, disconnect the negative battery

terminal before installing this product. Ensure

that all installation connections, especially the

air bag indicator lights, are plugged in before

reconnecting the battery or cycling the ignition

to test this product.

NOTE: Refer also to the instructions included

with the aftermarket radio.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip-ties

• Small ﬂat-blade screwdriver

TABLE OF CONTENTS

Connections .........................................................2-3

Installation .............................................................3

Programming .........................................................3

Audio level adjustment .........................................3

Wiring diagram ......................................................4

Toyota Digital Ampliﬁer Interface 2001-2015

• Designed for ampliﬁed models

• Retains balance and fade

• USB Micro-B updatable

• AXTO-TY1 harness

• AXTO-TY1 interface

• 16-pin harness with stripped leads

APPLICATIONS

See inside front cover

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date

vehicle speciﬁc applications

APPLICATIONS CONNECTIONS

LEXUS

ES Series 2007-2012

ES Series (w/ multi disc) 2002-2006

GS Series 2001-2005

IS Series 2002-2005

LS Series 2001-2006

RX Series 2004-2009

SC Series 2002-2010

TOYOTA

4-Runner 2003-2013

Avalon 2005-2010

Avalon 2011-2012

(Camry) Solara 2004-2008

Camry (w/o nav) 2012-2013

Camry 2007-2011

Corolla 2003-2011

TOYOTA (Cont.)

FJ Cruiser 2011-2014

Highlander 2008-2013

Highlander Hybrid 2008-2012

Matrix 2005-2012

Prius 3rd Gen (w/o nav) 2012-2015

Plug-In (PHV) (w/o nav) 2012-2015

Prius 2004-2011

Rav-4 2004-2013.5

Sequoia 2005-2012

Sequoia (w/o nav) 2013

Sienna 2004-2014

Tacoma 2005-2013

Tundra 2006-2013

Tundra (Double Cab) 2004-2005

Venza (w/ SD card based nav) 2013-2014

Venza 2009-2012

From the 16-pin harness with stripped leads to the aftermarket radio, connect as indicated:

• wire to the left front (+) speaker output.White

• wire to the left front (-) speaker output.White/Black

• wire to the right front (+) speaker output.Gray

• Gray/Black wire to the right front (-) speaker output.

• wire to the radio’s left rear (+) speaker output.Green

• wire to the radio’s left rear (-) speaker output.Green/Black

• wire to the radio’s right rear (+) speaker output.Purple

• wire to the radio’s right rear (-) speaker output.Purple/Black

• wire to the ampliﬁer turn on wire. Blue/White

Note: This wire must be connected to hear sound from the factory ampliﬁer.

Tape off and disregard the following (6) wires, they will not be used in this application:

Red, , , , Brown Light Green Blue/Pink Green/Purple Orange/White,

Continued on the next page

For refer toDash Disassembly Instructions, metraonline.com.

Enter the year, make, and model of the vehicle in the

Vehicle Fit Guide for Radio Install kits.
