From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the wire to the amplifier turn on wire. This wire must be connected to Blue/White
hear sound from the factory amplifier.
• Connect the wire to the right front positive speaker output.Gray
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative output.Purple/Black
• Tape off and disregard the following (6) wires, they will not be used in this application:
Blue/Pink Brown Green/Purple Light Green Orange/White, , , , , Red
From the AXTO-TY3 harness to the aftermarket radio:
• Connect the wire to the ground wire. There will also be a ground wire from the Black
backup
camera harness
to connect as well.
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• Connect the wire to the reverse wire, and also to the wire from Green/Purple Blue/White
the AXCSD-6V.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the and RCA jacks to the audio AUX-IN jacks from the aftermarket radiRed White
12-pin AXSWC harness & 3.5mm jack:
The 12-pin harness & 3.5mm jack is to be used with the AXSWC (sold separately) AXSWC
to retain steering wheel audio controls. If the is not being used, disregard this AXSWC
harness. If it is to be used, please refer to the instructions for radio connections anAXSWC
programming. Disregard the harness that comes with the AXSWC.
Backup camera harness:
• Connect the wire labeled “CAMERA GROUND”, to the ground from the Black AXTO-TY3
harness Black, and also to the wire from the AXCSD-6V.
• Connect the wire labeled “CAMERA POWER 6V”, to the wire from Red Blue/Red
the AXCSD-6V.
• Connect the Yellow RCA jack labeled “BACKUP CAMERA”, to the radios backup camera inpu
The following (1) wire is only for a multimedia/navigation radio that requires this wire.
• Connect the wire to the radios parking brake wire.Light Green
