Side 1/3
AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
AXVI-1784
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
Provides accessory (12 volt 10 amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, and V.S.S.)
Prewired AXSWC harness included (AXSWC sold separately)
High level speaker input
USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
Connect the wire to the radio’s ground wire.Black
Connect the wire to the ignition wire of the aftermarket radioRed
Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the wire.Orange
Connect the wire to the antenna turn on wire of the aftermarket radio.Blue
Connect the wire to the left front positive speaker output of the White
aftermarket radio.
Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
DODGE
Sprinter 2007
Sprinter (sound 5 radio) 2008-2009
MERCEDES
Sprinter (sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
