Side 1/3

AXVI-1785

1-800-221-0932 metraonline.com

AXVI-1785

Mercedes accessory and NAV output CAN Interface 2001-2004

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems, or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

WIRING THE AXVI-1785

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the wire to the radio’s ground wire.Black

• Connect the wire to the ignition wire of the aftermarket radio.Red

• Connect the wire to the illumination wire of the aftermarket radio. If the Orange

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the wire to the antenna turn on wire of the aftermarket radio.Blue

• Connect the wire to the left front positive speaker output of the White

aftermarket radio.

• Connect the wire to the left front negative speaker output of the White/Black

aftermarket radio.

MERCEDES

C Class 2001-2004

CLK Class 2004

CLK500 2003

CLK55AMG 2003

AXVI-1785

1-800-221-0932 metraonline.com

• Connect the wire to the right front positive speaker output of the Gray

aftermarket radio.

• Connect the wire to the right front negative speaker output of the Gray/Black

aftermarket radio.

• Connect the wire to the radio’s left rear positive speaker output.Green

• Connect the wire to the radio’s left rear negative speaker output.Green/Black

• Connect the wire to the radio’s right rear positive speaker output.Purple

• Connect the wire to the radio’s right rear negative speaker output.Purple/Black

The following wires are for the aftermarket radios that have navigation built in.

• Connect the wire to the parking brake wire of the aftermarket Light Green

navigation radio (if applicable).

• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink

navigation radio (if applicable).

• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple

radio (if applicable).

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to

test the radio.

AXSWC (if installing)

After the interface is initialized, plug in the AXSWC into the 12-pin harness of the

AXVI-1785 and refer to the AXSWC instructions.

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

K PNOWLEDGE IS OWER

Enhance your installat ion and fabrica tion skills by

enrolling in the most cognized and spected re re

mobile electronics s chool in our industry.

Log ont o www.installerinstit ute.com or call

800-354-6782 for mo informat ion and ta ke steps re

toward a bett er t omorrow.

Metra r ecommends MECP

certified technicians
