Installation Instructions for AXVI-2104

REV. 1/21/2020 INSTAXVI-2104

(continued on next page)

GM 2006-2012

AXVI-2104

GM LAN 11 accessory and NAV output interface WIRING THE AXVI-2104

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the wire to the radio’s ground wire.Black

• Connect the wire to the ignition wire of the aftermarket radio.Red

• Connect the wire to the illumination wire of the aftermarket radio. If the Orange

aftermarket radio has no illumination wire, tape off the Orange wire.

• The Orange/White wire will not be used in this application. Tape up or cap off this

wire and disregard it.

• Connect the wire to the antenna turn on wire of the aftermarket radio.Blue

• Connect the wire to the left front positive speaker output of the aftermarket radio.White

• Connect the wire to the left front negative speaker output of the White/Black

aftermarket radio.

• Connect the wire to the right front positive speaker output of the Gray

aftermarket radio.

• Connect the wire to the right front negative speaker output of the Gray/Black

aftermarket radio.

• Connect the wire to the radio’s left rear positive speaker output.Green

• Connect the wire to the radio’s left rear negative speaker output.Green/Black

• Connect the wire to the radio’s right rear positive speaker output.Purple

• Connect the wire to the radio’s right rear negative speaker output.Purple/Black

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 (5th digit of VIN must be a J, K, or L) 2009

G6 2010

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2006-2009

APPLICATIONS

KIT FEATURES

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

Note: All chimes will be lost when using this harness

AXVI-2104

REV. 1/21/2020 INSTAXVI-2104

The following wires are for the aftermarket radios that have navigation built in.

• Connect the wire to the parking brake wire of the aftermarket Light Green

navigation radio (if applicable).

• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink

navigation radio (if applicable).

• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple

radio (if applicable).

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to

test the radio.

AXSWC (if installing)

After the Interface is initialized, plug in the AXSWC into the 12-pin harness of the

AXVI-2104 and refer to the AXSWC instructions.

K PNOWLEDGE IS OWER

Enhance your installation and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take stepsre

toward a better tomorrow.

Metra recommends MECP

certified technicians

IMPORTANT WARNING

This product includes instructions for installation which must be carefully followed. The

instructions are worded in such a manner to assume that the installer is capable of

completing these type of electronic installations. If you are unclear as to what you are

instructed to do or believe that you do not understand the instructions so as to properly

and safely complete the installation you should consult a technician who does have this

knowledge and understanding.

Failure to follow these instructions carefully and to install the interface as described

could cause harm to the vehicle or to safety systems on the vehicle. Interference with

certain safety systems could cause harm to persons as well. If you have any questions

in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
