AXVI-5524

I N S T A L L A T I O N I N S T R U C T I O N S

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

NOTE: Refer to the instructions included with

the aftermarket radio.

INTERFACE FEATURES

• Provides accessory power (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

•

Provides illumination, parking brake, reverse, and speed sense outputs

• Prewired AXSWC harness

• Retains balance and fade

• USB Micro-B updatable

Note: The AXVI-5524 does not retain SYNC.

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors

• Solder gun, solder, and heat shrink

• Tape

• Wire cutter

• Zip-ties

• Multimeter tester

Ford Data Interface 2011-2019

APPLICATIONS

Ford

Escape (S trim) 2019

Escape (w/ 4.2-inch screen) 2013-2018

Fiesta (w/ SYNC) 2011-2013

Fiesta (w/o 6-inch MyFordTouch radio) 2014-2015

Fiesta (w/o 6-inch SYNC 3 radio) 2016-2019

Focus (w/o 6-inch MyFord Touch radio) 2012-2014

Transit (w/ CD player, w/o NAV) 2015-2019*

Transit Connect (w/ CD player, w/o NAV) 2015-2018

INTERFACE COMPONENTS

• AXVI-5524 Interface

• AXVI-5524 Harness

• AXSWC Interface (sold separately)

TABLE OF CONTENTS

Connections ............................................................2

Installation .............................................................3

Programming .........................................................3

* The Ford Transit requires the purchase of AXSWCH-FD1 harness to retain steering

wheel controls.

Product Info

CONNECTIONS

From the 16-pin harness with stripped leads to the aftermarket radio, connect as indicated:

• wire to the ground wire.Black

• Yellow wire to the battery wire.

• wire to the accessory wire.Red

• Orange wire to the illumination wire (if applicable).

• wire to the power antenna wire.Blue

• wire to the front right (+) speaker output.Gray

• Gray/Black wire to the front right (-) speaker output.

• White wire to the front left (+) speaker output.

• White/Black wire to the front left (-) speaker output.

• Green wire to the rear left (+) speaker output.

• Green/Black wire to the rear left (-) speaker output.

• wire to the rear right (+) speaker output.Purple

• wire to the rear right (-) speaker output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Light Green wire to the parking brake wire.

• wire to the VSS or speed sense wire.Blue/Pink

• Green/Purple wire to the reverse wire.

Steering Wheel Control Retention:

If the vehicle has steering wheel controls, an additional AXSWC interface will need to be

purchased to retain steering wheel controls.

Note: Disregard the harness that comes with the AXSWC.

For connection instructions visit www.axxessinterfaces.com Enter the year, make, and

model of the vehicle in the Vehicle Fit Guide and follow the AXSWC Installation Instructions.
