INSTAXVI-9005
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Connections to be made
• Connect the Yellow wire to the radio’s 12-volt battery or memory wire.
• Connect the wire to the radio’s ground wire.Black
• Connect the wire to the ignition wire of the aftermarket radio.Red
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the Orange wire.
AXVI-9005
Mercedes accessory and NAV output CAN
Interface 2005-up
APPLICATIONS
FREIGHTLINER
Sprinter 2014-up
MERCEDES
C Class 2005-2011
CLK Class 2005-2009
E Class 2010-up
G Class 2007-2012
GLK Class 2010-2012
R Class 2006-2011
SLK Class 2005-2011
Sprinter 2010-up
FEATURES
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
Caution: Metra recommends disconnecting the negative battery terminal before beginning
any installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*Note: Refer also to the instructions included with the aftermarket radio.
INSTAXVI-9005
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
• Connect the wire to the antenna turn on wire of the Blue
aftermarket radio.
• Connect the wire to the left front positive speaker output of the White
aftermarket radio.
• Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
• Connect the wire to the right front positive speaker output of the Gray
aftermarket radio.
• Connect the wire to the right front negative speaker output of the Gray/Black
aftermarket radio.
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right rear positive speaker output.Purple
• Connect the wire to the radio’s right rear negative speaker output.Purple/Black
The following wires are for the aftermarket radios that have navigation built in.
• Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio (if applicable).
• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
• Connect the wire to the reverse wire of the aftermarket navigation Green/Purple
radio (if applicable).
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to
test the radio.
AXSWC (if installing)
After the Interface is initialized, plug in the AXSWC into the 12-pin harness of the
AXVI-9005 and refer to the AXSWC instructions.
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most cognized and spect ed re re
mobile electronics s chool in our industry.
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information a nd t ake st eps re
toward a bett er t omorrow.
Metra r ecommends MECP
certified technicians
