Installation Instructions for AXVRI

REV. 2/3/2020 INSTAXVRI

AXVRI

Voltage Retention Interface

CONNECTIONS TO BE MADE

From the 8-pin harness to the vehicle-side harness:

• Connect the (3) wires to the ground wire.Black

• Connect the Yellow fused wire to the battery wire.

• Connect the fused wire to the accessory wire.Red

From the 6-pin harness to the aftermarket radio:

• Connect the (2) wires together, then connect them to Black/White

the ground wire.

• Connect the (2) Yellow/White wires together, then connect them to the

battery wire.

• Connect the (2) wires together, then connect them to the Red/White

accessory wire.

Note: Each individual line is rated at 5-amps per line (10-amps

combined total). If each line is going to be used for separate sources--

or the current will surpass 10-amps--please use a relay, Metra part

number E-123 to increase current.

Caution: Metra recommends disconnecting the negative battery terminal before beginning

any installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

INTERFACE COMPONENTS

• AXVRI Interface • 8-pin harness with stripped leads and fuses

• 6-pin harness with stripped leads

TOOLS REQUIRED

• Cutting tool • Tape • Crimping tool

• Connectors (i.e. butt-connectors, bell caps, etc.)

FEATURES

• Provides 12-volt output when voltage drops below 7-volts

• Designed for vehicles that drop voltage while stopped

• Fuses included for safety

• Provides accessory power (12-volt 10-amp)

AXVRI

K PNOWLEDGE IS OWER

Enhance your inst allation and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take stepsre

toward a better t omorrow.

Metra recommends MECP

certified technicians

IMPORTANT WARNING

This product includes instructions for installation which must be carefully followed. The

instructions are worded in such a manner to assume that the installer is capable of

completing these type of electronic installations. If you are unclear as to what you are

instructed to do or believe that you do not understand the instructions so as to properly

and safely complete the installation you should consult a technician who does have this

knowledge and understanding.

Failure to follow these instructions carefully and to install the interface as described

could cause harm to the vehicle or to safety systems on the vehicle. Interference with

certain safety systems could cause harm to persons as well. If you have any questions

in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
