Installation Instructions for GMRC-03

REV. 11/14/2013 INSTGMRC-03

(continued on next page)

GMRC-03

GM Class II data bus interface

1996-2002

• Provides accessory (12-volt 10-amp)

• Retains R.A.P. (Retained Accessory Power), if equipped

• Used in non-amplified systems or when replacing amplified systems

• Retains all warning chimes through onboard speaker

KIT FEATURES

• GMRC-03 data interface

• 10-pin to 24-pin GM harness with stripped leads

INTERFACE COMPONENTS

• Cutting tool • Crimping tool • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

CADILLAC

Catera 1997-2001

Deville 1996-1999

Eldorado 1996-2002

Seville 1996-1999

APPLICATIONS

CONNECTIONS TO BE MADE

From the 10-pin harness:

• Connect the Yellow wire to the to the radio’s 12-volt battery or memory wire.

• Connect the wire to the radio’s 12-volt accessory or switched wire.Red

• Connect the wire to the radio’s ground wire.Black

• When completed plug the 10-pin harness into the GMRC-03.

From the 32-pin harness:

• Connect the wire to the radio’s antenna turn-on wire. If no antenna turn-on Blue

wire is present, hook wire to the radio’s amplifier turn-on wire.Blue

• Connect the wire to the radio’s dimmer wire. If your radio does Orange/White

not have a dimmer wire, just tape off wire.

• Connect the wire to the radio’s left front positive speaker output.White

• Connect the wire to the radio’s left front negative speaker output.White/Black

• Connect the wire to the radio’s left rear positive speaker output.Green

• Connect the wire to the radio’s left rear negative speaker output.Green/Black

• Connect the wire to the radio’s right front positive speaker output.Gray

• Connect the wire to the radio’s right front negative Gray/Black

speaker output.

• Connect the wire to the radio’s right rear positive speaker output.Purple

• Connect the wire to the radio’s right rear negative Purple/Black

speaker output.

GMRC-03

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

K PNOWLEDGE IS OWER

Enhance your inst allation and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take steps re

toward a better t omorrow.

Metra recommends MECP

certiﬁed technicians

Note: If the chime volume of the GMRC-03 is too loud you will need to remove the cover and

cut the solder connection where the arrow points to on the circuit board (between the holes

on the board).

Cut for low volume

installinG the Gmrc-03

• With all connections completed to the aftermarket radio, plug the 32-pin

harness into the vehicles wiring harness.

• Reconnect the negative battery terminal.

• Cycle the key by turning the ignition on for 30 seconds. Then off and on again

to test the radio.

• Mount the GMRC-03 in a location where the internal speaker will be heard.
