INSTALLATION INSTRUCTIONS FOR PART HYBL-05

REV. 7/24/2013 INSTHYBL-05

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

• RetainsfactoryBluelink

• Providesnavigationoutputs

• USBupdatable

• Retainsfadeandbalance

• Usedinnon-amplifiedsoundsystems

• Retainsfactorybackupcamera

• Retainsfactory3.5mmjack

• Highlevelspeakerinput

• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)

KIT FEATURES

•Cuttingtool•Crimpingtool•Tape•Connectors

(example:butt-connectors,bellcaps,etc.)

TOOLS REQUIRED

Hyundai Veloster Blue Link interface

2011-up

APPLICATIONS

•HYBL-05Interface•16-pinharnesswith

strippedleads•18-pinto24-&18-pinconnector

INTERFACE COMPONENTS

HYUNDAI

Veloster 2011-up

HYBL-05

• Connectthe wiretothegroundwireoftheaftermarketradio.Black

• Connectthe wiretothepowerantennawireoftheaftermarketBlue  

radio.Iftheaftermarketradiodoesnothaveapowerantennawiretape

offthe wire.Blue

• Connectthe wiretotheilluminationwireoftheaftermarketradio.Orange

Iftheaftermarketradiohasnoilluminationwire,tapeoffthe wire.Orange

• Connectthe wiretotheparkingbrakewireoftheaftermarketLight Green

navigationradio.

• Co

nnectthe and RCAtotheaftermarketradiosAUXinput.White Red

From the 2nd 24-pin harness:

• ConnecttheYellowRCAtothevideoinoftheaftermarketradio.

From the 18-pin harness:

• Connectthe wiretotheVSSorspeedsensewireoftheaftermarketBlue/Pink

navigationradio.

• Connectthe wiretothereversewireoftheaftermarketGreen/Purple

navigationradio.

• Connectthe wiretotheradio’sleftrearpositivespeakeroutput.Green

• Connectthe wiretotheradio’sleftrearnegativespeakeroutput.Green/Black

From the 16-pin harness with stripped leads:

• Connectthe wirestotheignitionwireoftheaftermarketradio.Red

• Connectthe wiretotheleftfrontpositivespeakeroutputoftheWhite

aftermarketradio.

• Connectthe wiretotheleftfrontnegativespeakeroutputoftheWhite/Black

aftermarketradio.

• Connectthe wiretotherightfrontpositivespeakeroutputoftheGray

aftermarketradio.

• Connectthe wiretotherightfrontnegativespeakeroutputoftheGray/Black

aftermarketradio.

• Connectthe wiretothemutewireoftheaftermarketradio.IftheBrown

aftermarketradiodoesnothaveaMutewire,tapeupthe wire.Brown

• The willnotbeusedinthisapplication.Blue/Pink

• The wirewillnotbeusedinthisapplication.Green/Purple

• The wirewillnotbeusedinthisapplication.Orange/White

• The wirewillnotbeusedinthisapplication.Light Green

From the 1st 24-pin harness:

• ConnecttheYellowwiretothe12-voltconstant/batterywireof 

theaftermarketradio.

Connections to be made
