INSTALLATION INSTRUCTIONS FOR PART TRIGGER
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2013 METRA ELECTRONICS CORPORATION
REV. 12/30/2013 INSTTRIGGER
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
The “Trigger” is a universal module the provides 14 different preset functions that are
activated from a positive or negative trigger. In addition, to the preset features, the
Trigger has 8 custom modes with customizable settings that allows the installer to
utilize their imagination.
KIT FEATURES
• Cutting tool • Crimping tool • Tape • Connectors
(example: butt-connectors, bell caps, etc.)
TOOLS REQUIREd
APPLICATIONS
N/A - Universal module • TRIGGER
INTERFACE COMPONENTS
TRIGGER
Table of Contents
General
– Pin diagram ....................................................................................................... 3
Mode descriptions and wiring instructions .....................................................3-8
– Mode 1: Retained accessory power .................................................................... 4
– Mode 2: Delayed amp turn-on ............................................................................ 4
– Mode 3: Low voltage turn-on ............................................................................. 4
– Mode 4: Latched outputs .................................................................................... 4
– Mode 5: GMLAN aftermarket amp turn-on .......................................................... 5
– Mode 6: Active edge pulse generator .................................................................. 5
– Mode 7: Turn-off delay ....................................................................................... 6
– Mode 8: Double pulse latch ................................................................................ 6
– Mode 9: Double pulse to one-second output ....................................................... 6
– Mode 10: Theft detection/closed loop trigger ...................................................... 7
– Mode 11: Channel expander ............................................................................... 7
– Mode 12: Simple data detector (amp turn-on signal from data) ................................ 7
– Mode 13: Long delayed turn-off (for headlights) .................................................... 8
– Mode 14: Dome light delay ................................................................................. 8
– Mode 15: Custom program ................................................................................. 8
Custom program modes
– Custom Mode 1: Channel expander, latched ....................................................8-9
– Custom Mode 2: Channel expander, pulsed ........................................................ 9
– Custom Mode 3: Delayed turn-off ..................................................................... 10
– Custom Mode 4: Delayed turn-on ..................................................................... 10
– Custom Mode 5: Delayed three-output delay/pulse width, edge driven
(for use with linear actuators) ..........................................................................10-11
– Custom Mode 6: Generic three-output delay/pulse width, level driven (validity) .... 11
– Custom Mode 7: Square wave-generator (sounds horns, blinks lights) .............11-12
– Custom Mode 8: Multiple pulse generator ........................................................ 12
