B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

PROJECTOR MOUNTceiling

INSTALLATION GUIDE

Installation Safety Notes.....................................................................................................................2

BT5890-010 Installation Instructions.......................................................................................................4

BT5890-075 & BT5890-150 Installation Instructions...............................................................................5

Product Dimensions..........................................................................................................................10

B-Tech Contact Details.....................................................................................................................12

PLEASE KEEP THIS FOR FUTURE REFERENCE

The System V range is available in™

package or component form.

This installation guide demonstrates

how to install and use the System V™

projector mounting range from

B-Tech.

REGISTERED DESIGN

Flathead

screwdriver Drill Pencil

10mm (7/16") masonry bit

or 6mm (1/4") wood bit

13mm (1/2") spanner

or socket

Saw

(Optional)

BT5890-010

BT5890-075

BT5890-150

INSTALLATION SAFETY INSTRUCTIONS

CAUTION:

This mount is intended for use

only with the maximum weights indicated. Use with

ﬂat screens heavier than the maximum indicated may result

in instability causing possible injury.

Do not attempt to install this product until all instructions and warnings have been read and properly

understood. Please keep these instructions for future reference.

B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or

injury caused by improper installation, improper use or failure to observe these safety instructions. In

such cases, all guarantees will expire.

General

B-Tech International Ltd recommends that a professional AV installer or other suitably qualiﬁed

person install this product. Great care must always be taken during installation as most AV equipment

is of a fragile nature, possibly heavy and easily damaged if dropped.

If you do not fully understand the instructions or are not sure how to install this product safely, then

please consult a professional for advice and/or to install this product for you. Failure to mount this

product correctly may cause serious injury or death both during installation and at any time thereafter.

Do not mount any AV equipment that exceeds the speciﬁc weight limit of the product you are

installing. This weight limit will be clearly stated on each product and its packaging and will vary from

product to product.

Product location

Please pay careful attention to where this product is located. Some ceilings are not suitable for

installation.

If located in a public or frequently populated area ensure that the product is out of the immediate

reach of people. If any AV equipment is to be suspended over the likely path or location of people

then great care should be taken to secure all parts of the installation from falling.

If you install this product on drywall it must be securely ﬁxed to a wooden stud, concrete block or other

permanent structure behind the drywall board. Installing on drywall boards alone will not support the

weight o

f most AV equipment.

When drilling holes in walls it is essential to avoid contact with electrical cables and water or gas pipes

contained within. Use of a good quality live wire detector and hidden object locator is therefore

recommended. Only drill into structures when you are sure it is safe to do so.

Fixing hardware

It is highly recommended that all wall ﬁxing screws be used where supplied and that the purpose of all

other ﬁxing hardware is fully understood. In some cases more AV equipment ﬁxing hardware will be

supplied to accommodate diﬀerent models of equipment and set up conﬁgurations.

The installer must be satisﬁed that any supplied ﬁxing hardware is suitable for each speciﬁc

installation. If any ﬁxing screws or included hardware are deemed not suﬃcient for a safe installation

then please consult a professional or your local hardware store.

Hazard limitation

When routing cables take advantage of any built in cable management features that the product might

provide and ensure that all cables are tidy and secure. Check to see that any moving aspect of the

product can do so unhindered by any cabling.

Some products have moving parts and the potential to cause injury through the crushing or trapping of

ﬁngers or other body parts.

Particula

r attention to the nature of moving parts is required especially when assembling installing and

adjusting during set up.

Immediately after installations double-check that the work done is safe and secure. Double-check all

necessary ﬁxings are present and are of ample tightness.

It is recommended that periodic inspections of the product and its ﬁxing points are made as frequently

as possible to ensure that safety is maintained. If in doubt consult a professional AV installer or other

suitably qualiﬁed person.
