BT9920

XXL DISPLAY Wall Mount

INSTALLATION GUIDE

• Designed to wall mount extra large signage displays up

to 120” such as LG's 110UM5J

• Suitable for standard or interactive screens over 72"

• Max load: 200kg (440lbs)

• Fits screens with VESA

and non-VESA xings up

to 1600 x 800mm

• Low profile design mounts screen 52mm (2") from wall

• Cable management

• Simple ‘hook-on’ installation with all mounting

hardware included

SPECIFICATIONS

www.btechavmounts.com

B-TECH AV mounts

Please pay careful attention to where this product is located. Check load capacity of the wall prior to installation as

some surfaces are not suitable for installation. Designed for indoor use, this mount is suitable for public or home installation.

If located in a public or frequently populated area ensure that the product is out of the immediate reach of people.

If any AV equipment is to be suspended over the likely path or location of people then great care should be taken to

secure all parts of the installation from falling.

When drilling holes it is essential to avoid contact with electrical cables and water or gas pipes contained within.

Use of a good quality live wire detector and hidden object locator is therefore recommended.

Only drill into structures when you are sure it is safe to do so.

CONTENTS

Installation Safety Notes......................................................................................................................

Parts List....................................................................................................................................................

Installation Instructions.......................................................................................................................

Pole Mounting.......................................................................................................................................

Product Dimensions............................................................................................................................

B-Tech Contact Details........................................................................................................................

INSTALLATION SAFETY INSTRUCTIONS

CAUTION:

Do not attempt to install this product until all instructions and warnings have been read and properly understood.

Please keep these instructions for future reference.

Please check carefully to make sure there are no missing or defective parts - defective parts must never be used.

B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper

installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.

General

B-Tech AV Mounts recommends that a professional AV installer or o

the

r suitably qualied person install this product.

Great care must always be taken during installation as most AV equipment is of a fragile nature, possibly heavy and

easily damaged if dropped.

If you do not fully understand the instructions or are not sure how to install this product safely, then please consult a

professional for advice and/or to install this product for you. Failure to mount this product correctly may cause serious

injury or death both during installa

tion

and at any time thereafter.

Do not mount any AV equipment that exceeds the specic weight limit of the product you are installing.

This weight limit will be clearly stated on each product and its packaging and will vary from product to product.

Product location

Fixing hardware

It is highly recommended that all xing screws be used where supplied and that the purpose of all other xing hardware

is fully understood. In some cases more AV equipment xing hardware will be supplied to accommodate dierent models

of equipment and set up congurations. The installer must be satised that any supplied xing hardware is suitable for

each specic installation. The xing kit supplied with the product may not be suitable for all walls.

If any xing screws or included hardware are deemed not sucient for a safe installation then plea

se consult a professional

or your local hardware store.

Hazard limitation

When routing cables take advantage of any built in cable management features that the product might provide and ensure

that all cables are tidy and secure. Check to see that any moving aspect of the product can do so unhindered by any cabling.

Some products have moving parts and the potential to cause injury through the crushing or trapping of ngers or other

body parts.

Particular attention to the nature of moving parts is required especially when assembling installing and adjusting

during set up.

Immediately after installation double-check that the work done is safe and secure. Double-check all

necessary xings are present and are of ample tightness.

It is recommended that periodic inspections of the product and its xing points are made as frequently as possible (no more

than 6 months apart) to ensure that safety is maintained.

If in doubt consult a professional AV installer or other suitably qualied person.

This mount is intended for use only with the

maximum weights indicated. Use with equipment heavier than the maximum

indicated may result in instability causing possible injury.

Produkt Specifikationer

Mærke:	B-Tech
Kategori:	Flad panel støtte
Model:	BT9920
Bredde:	1755 mm
Dybde:	51.8 mm
Højde:	889.5 mm
Produktfarve:	Sort
Monteringstype:	Væg
Maksimal vægtkapacitet:	200 kg
Maksimal skærmstørrelse kompatibilitet:	120 "
Orientering:	Landskab
Antal understøttede skærme:	1
Minimal skærmstørrelse kompatibilitet:	72 "
Montering interface kompatibilitet (min.):	- mm
Montering interface kompatibilitet (maks.):	1600 x 800 mm
