Side 1/16

BT883

PROJECTOR CEILING MOUNT

WITH ADJUSTABLE DROP

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Product Dimensions..........................................................................................................................15

B-Tech Contact Details.....................................................................................................................16

B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

12mm (1/2") masonry bit

or 8mm (11/32") wood bit

Level

(optional)

PLEASE KEEP THIS FOR FUTURE REFERENCE

Crosshead

screwdriver

Drill

Pencil

13mm (1/2") spanner

or socket

REG. DESIGN NO: 3016251

● Suitable for projectors up to 10kg (22lbs)

● Hand lever for easy adjustment of ceiling drop:

Min 750mm (29.5”) – Max 1222mm (48”)

● +/-90° tilt adjustment, +/-90° roll adjustment & 360° swivel

● Unique ‘carousel’ mounting plate for universal compatibility

● Suitable for angled / cathedral ceilings

● Integrated cable management

● Maximum distance between any two fixing points on

projector: 340mm (13.5”)

● Suitable for projectors with M2.5, M3, M4, M5 and M6 fixings

● Simple installation with all mounting hardware and fixings included

REG. DESIGN NO: 3016251

INSTALLATION SAFETY INSTRUCTIONS

CAUTION: This ceiling mount is intended for use only with the maximum

weights indicated. Use with projectors heavier than the maximum indicated

may result in instability causing possible injury.

Do not attempt to install this product until all instructions and warnings have been read and

properly understood. Please keep these instructions for future reference.

B-Tech International Limited, its distributors and dealers are not liable or responsible for

damage or injury caused by improper installation, improper use or failure to observe these

safety instructions. In such cases, all guarantees will expire.

General

B-Tech International Ltd recommends that a professional AV installer or other suitably qualified

person install this product. Great care must always be taken during installation as most AV

equipment is of a fragile nature, possibly heavy and easily damaged if dropped.

If you do not fully understand the instructions or are not sure how to install this product safely,

then please consult a professional for advice and/or to install this product for you. Failure to

mount this product correctly may cause serious injury or death both during installation and at

any time thereafter.

Do not mount any AV equipment that exceeds the specific weight limit of the product you are

installing. This weight limit will be clearly stated on each product and its packaging and will

vary from product to product.

Product location

Please pay careful attention to where this product is located. Some ceilings are not suitable for

installation.

If located in a public or frequently populated area ensure that the product is out of the

immediate reach of people. If any AV equipment is to be suspended over the likely path or

location of people then great care should be taken to secure all parts of the installation from

falling.

When drilling holes in ceilings it is essential to avoid contact with electrical cables and water or

gas pipes contained within. Use of a good quality live wire detector and hidden object locator is

therefore recommended. Only drill into structures when you are sure it is safe to do so.

Fixing hardware

It is highly recommended that all wall fixing screws be used where supplied and that the

purpose of all other fixing hardware is fully understood. In some cases more AV equipment

fixing hardware will be supplied to accommodate different models of equipment and set up

configurations.

The installer must be satisfied that any supplied fixing hardware is suitable for each specific

installation. If any fixing screws or included hardware are deemed not sufficient for a safe

installation then please consult a professional or your local hardware store.

Hazard limitation

When routing cables take advantage of any built in cable management features that the

product might provide and ensure that all cables are tidy and secure. Check to see that any

moving aspect of the product can do so unhindered by any cabling.

Some products have moving parts and the potential to cause injury through the crushing or

trapping of fingers or other body parts.

Particular attention to the nature of moving parts is required especially when assembling

installing and adjusting during set up.

Immediately after installations double-check that the work done is safe and secure. Double-

check all necessary fixings are present and are of ample tightness.

It is recommended that periodic inspections of the product and its fixing points are made as

frequently as possible to ensure that safety is maintained. If in doubt consult a professional AV

installer or other suitably qualified person.

Produkt Specifikationer

Mærke:	B-Tech
Kategori:	Flad panel støtte
Model:	BT883
Produktfarve:	Sølv
Monteringstype:	Væg
Maksimal vægtkapacitet:	10 kg
Teleskopisk:	Ja
Afstand til væggen (min.):	830 mm
Afstand til væggen (maks.):	1330 mm
