Side 1/16

B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

BT8505

LARGE FLAT SCREEN DISPLAY TROLLEY

WITH GLASS BASE

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Trolley

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Safety Instructions...................................................................................................................................6

Installation Instructions.......................................................................................................................7

Optional Accessories.............................................................................................................................14

Product Dimensions..........................................................................................................................15

B-Tech Contact Details.....................................................................................................................16

PLEASE KEEP THIS FOR FUTURE REFERENCE

Hex Key's

(Supplied)

CAUTION!! GLASS

This item contains glass -

Handle with care to avoid

damage or injury

Crosshead

screwdriver

● Designed for flat screens up to 50” (127cm) / 40kg (88lbs)

● Fits screens with mounting patterns up to:

H: 700mm (27.6”) x V: 400mm (15.7”) including all

VESA fixings up to 600 x 400mm

● Easy tilt adjustment +15° / -5°

● Cable management

● 10mm (0.4”) tempered safety glass base

● Meets British Standard BS6206

Community Design No. 001713280-0050

INSTALLATION SAFETY INSTRUCTIONS

CAUTION:

This trolley is intended for use

only with the maximum weights indicated. Use

with flat screen heavier than the maximum

indicated may result in instability causing possible injury.

Do not attempt to install this product until all instructions and warnings have been read and

properly understood. Please keep these instructions for future reference.

B-Tech International Limited, its distributors and dealers are not liable or responsible for

damage or injury caused by improper installation, improper use or failure to observe these

safety instructions. In such cases, all guarantees will expire.

General

Great care must always be taken during installation as most AV equipment is of a fragile nature,

possibly heavy and easily damaged if dropped.

If you do not fully understand the instructions or are not sure how to install this product safely, then

please consult a professional for advice and/or to install this product for you. Failure to mount this

product correctly may cause serious injury or death both during installation and at any time thereafter.

Do not mount any AV equipment that exceeds the specific weight limit of the product you are

installing. This weight limit will be clearly stated on each product and its packaging and will vary from

product to product.

Product location

Please pay careful attention to where this product is located. Some locations are not suitable for

installation.

If located in a public or frequently populated area ensure that the product is out of the immediate

reach of people.

Fixing hardware

It is highly recommended that all fixing screws be used where supplied and that the purpose of all

other fixing hardware is fully understood. In some cases more AV equipment fixing hardware will be

supplied to accommodate different models of equipment and set up configurations.

The installer must be satisfied that any supplied fixing hardware is suitable for each specific

installation. If any fixing screws or included hardware are deemed not sufficient for a safe installation

then please consult a professional or your local hardware store.

Hazard limitation

When routing cables take advantage of any built in cable management features that the product might

provide and ensure that all cables are tidy and secure. Check to see that any moving aspect of the

product can do so unhindered by any cabling.

Some products have moving parts and the potential to cause injury through the crushing or trapping of

fingers or other body parts.

Particular attention to the nature of moving parts is required especially when assembling installing and

adjusting during set up.

Immediately after installations double-check that the work done is safe and secure. Double-check all

necessary fixings are present and are of ample tightness.

It is recommended that periodic inspections of the product and its fixing points are made as frequently

as possible to ensure that safety is maintained. If in doubt consult a professional AV installer or other

suitably qualified person.

Produkt Specifikationer

Mærke:	B-Tech
Kategori:	Flad panel støtte
Model:	BT8505
Type:	Transportabelt gulvstativ
Bredde:	1000 mm
Dybde:	500 mm
Højde:	1910 mm
Vægt:	- g
Produktfarve:	Sort
Panel montering grænseflade:	200 x 100,200 x 200,300 x 300,300 x 200,400 x 200,400 x 400,600 x 400 mm
Monteringstype:	Gulv
Hældningsvinkelområde:	-5 - 15 °
Monteringssæt:	Ja
Maksimal vægtkapacitet:	40 kg
Hjul:	Ja
Forbedret kabelstyring:	Ja
Maksimal skærmstørrelse kompatibilitet:	55 "
Antal understøttede skærme:	1
Montering interface kompatibilitet (min.):	200 x 100 mm
Montering interface kompatibilitet (maks.):	600 x 400 mm
Indeholdt antal hylder:	1
Minimum afstand til gulvet:	1890 mm
Bredde (med fod):	1000 mm
Dybde (med fod):	500 mm
Maksimum størrelse:	55 "
Maksimal afstand til gulv:	1910 mm
Dybde, mellem-hylde:	320 mm
Bredde, mellem-hylde:	450 mm
