Side 1/8
GB -1-
ww
Chart
PROGRAM SELECTION
BUTTON
Push “Programs” button
(repeatedly) until the indicator
of the required program lights
up (see “Table of programs”
below).
START/RESUME BUTTON
Push this button to start the selected program: the
indicator lights up and goes off at the end of the
program.
When the door is opened during a washing cycle,
the cycle is temporarily paused: the Start indicator
blinks. To resume the cycle close the door and
push Start button again.
(see at right for options description)
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute (0:01
is shown into the display).
If pressed when the dishwasher is switched off, it
drains any possible liquids from dishwasher
(1minute process).
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional
options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the
appliance’s automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the
EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
Table of programs
Deter-
gent
Consumption
PPrograms Available
options Loading instructions Litres kWh Minutes 1)
1Sensor 40-70°C
Delay
Multizone
Antibacterial
rinse
Normally or heavily soiled crockery,
including pots and pans. None soaking
or hand pretreatment is needed. In
addition hygiene of the complete
loading is ensured with this program.
X 7-14 0.99-1.80 70-185
2Pre-Wash cold Delay
Multizone Crockery to be washed later. — 4.0 0.03 14
3Glasses 40°C Delay
Multizone Light soiling, for example glasses and
cups. X 10.0 0.85 100
4Quickwash 45°C Delay
Multizone Lightly soiled crockery, with no dried-
on food. X 11.0 0.80 30
5Bio Normal 2) 50°C
Delay
Multizone
Antibacterial
rinse
Normally soiled crockery. X 12.0 1.05 150
6Daily 60°C
Delay
Multizone
Antibacterial
rinse
Normally to heavily soiled crockery. X 13.0 1.25 120
5019 496 01635GSF EXCELLENCE
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
Options and display description
SALT INDICATOR
When lit (at the end of the cycle),
the salt reservoir needs to be
refilled.
MULTIZONE
Allows you to choose the washing
zones. Press this button (repeatedly)
to select the wash zones:
both racks
only lower rack
only upper rack
- indicator lits TABLET SETTING
This setting allows to
optimize the cycle
performances according
the type of detergent
used. Push the Tablet
button for 3 seconds (until
the indicator lights up) if
you are using the
combined detergents in
tablet (rinse aid, salt and
detergent in 1 dose). If you
are using powder
detergent or liquid
detergent, the Tablet
indicator on the control
panel has to be off.
DELAYED START
BUTTON
Push the button
(repeatedly) to delay the
start of the program.
Adjustable from 1 to 24
hours. With each press of
the button, the delayed
start indicator increases
by one hour and after 24
restarts from 0. Then
press the START button.
The dishwasher will start
after the set time.
RINSE AID INDICATOR
When lit (at the end of the cycle),
the rinse aid dispenser needs to
be refilled.
WASH TIME DISPLAY
Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates
the time remaining until program start (h.00) - below 1h (0:mim).
If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.
ANTIBACTERIAL RINSE 3)
This function activates an
antibacterial rinse at the end of the
wash cycle, guaranteeing a further
reduction of bacteria. Press the
button to activate or deactivate the
function. This function can be used
with the programs indicated in the
table of programs. The dishwasher
door must be kept shut for the entire
duration of the program in order to
guarantee reduction of bacteria. If
the door is opened the indicator lamp
starts flashing.
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING
ANY BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.
Quick reference guide
GB -2-
First time use
1- salt reservoir
2- rinse aid dispenser
3- detergent dispenser
4- racks system
5,6,7,8- available functions on the panel
9- filters
10- spray arms
Water hardness should be set only
before the first wash or if water
hardness has been changed
1Visual indicator
(depending
on the model).
Unscrew cap.
Fill the salt reservoir with water
before the first wash only.
(depending on the model)
The salt level indicator lamp may remain lit
at the end of several wash cycles. If the
water hardness level falls within category
(soft), no salt is required.
Salt indicator on the control panel Salt indicator on the salt reservoir cap
The indicator lamp lights up when SALT
NEEDS TO BE ADDED. green: OK. clear: NEEDS TO
BE ADDED
Daily check
Filling the salt reservoir - Dissolve limescale (not necessary if water hardness level is set to “soft”!)
- Press and hold together Programs and buttons for minimum 3 seconds.CANCEL/Off
- The current water hardness setting will be visible on the display.
- Press the Programs button to increase setting. Value range goes from 1 to 7 (when the level reaches 7, the next press of
the start button will set the level back to 1).
- Wait 30 seconds (control panel switches off) or press Start/Resume button to save setting.
Add salt (never add detergent!)
min. 0.8 kg / max. 1 kg
Screw on the cap.
Salt residual
around the cap
need to be
removed. Some
salt reservoir have
a level indicator
integrated in the
cap (see below
how to check).
At first time use, the salt reservoir has to be filled independently from water hardness level (see description below in step 1 “Daily check”).
1. Ask your water supply company what the water hardness is... 2. ...enter this value on
your dishwasher Suggestions for detergent use
German
degrees °dH
French
degrees °fH
English
degrees °eH
Water hardness
level
Insert value is shown
in the display
Gel or Powder
(rinse aid and salt) Tablets
0 - 5 0 - 9 0 - 6.3 Soft 1
go to step 1
(see “Daily
check”)
6 - 10 10 - 18 7 - 12.6 Medium 2
11 - 15 19 - 27 13.3 - 18.9 Average 3
16 - 21 28 - 37 19.6 - 25.9 Medium-hard 4 if water is
HARD extra salt
needs to be added
(go to step 1,
“Daily check”)
22 - 28 38 - 50 26.6 - 35 Hard 5
29 - 35 51 - 63 35.7 - 44.1 Very hard 6
36 - 50 64 - 90 44.8 - 62.4 Extremely hard 7
Water hardness level is factory
set for medium-hard water
(level 4).
Even if you use tablets which
include salt functionality, you
must still add regeneration salt
since such detergents are not
effective enough at softening
hard water.
How to set water hardness in order to always assure the best cleaning results
