Side 1/3

80161785

Push-button 1gang, RGB LED, int. temp. sensor, KNX-S.1/B.3/B.7, f. ant. + al.

Technical characteristics

Architecture

Fixing mode flush-mounting

Functions

With room temperature controller No

Easy link functions

operating concept "independent push-button"

function predefined, operating concept for "roller

shutter/blind" function predefined, switching of

scenes (1..8) possible, Orientation LED can be

controlled via object, brightness value of the status

LED for day/nighttime operation preset, status LED

for day/nighttime operation can be controlled via

object, integrated temperature sensor with output of

the measured values, Colour of status LED uniformly

adjustable for complete device, push-button

functions: including switching, dimming, roller

shutter/blind, timer, priority, temperature setpoint

adjustment, operating mode changeover

Function

Function for manual interruption of automatic

functions already triggered

Function

operating surfaces as buttons (single-surface

operation) and rockers (two-surface operation), the

brightness of status LEDs are individually adjustable

for button/ rocker function, brightness value of the

status LEDs for day/nighttime operation adjustable

via object or manually, value transmitter for

dimming, position, brightness temperature values 1

and 2 byte, button/rocker functions for switching,

dimming, roller shutter/blind, value transmitter 1/2

byte, room thermostat extension unit, priority,

scene, automatic control deactivation, integrated

temperature sensor with output of the measured

values via object, button functions for switching,

dimming, roller shutter/blind, timer, value

transmitter 1/2 byte, room thermostat extension

unit, priority, scene, 2-channel mode, step switch,

automatic control deactivation, rocker functions for

switching, dimming, roller shutter/blind, value

transmitter 1/2 byte, room thermostat extension

unit, priority, scene, 2-channel mode, automatic

control deactivation, parameter defineable lock

function, 3-step switch, function for incremental

selection of up to 7 stored values, Status LED

configurable in its colour per button

Compatibility

Extension unit extension unit for light scene push-button

Controls and indicators

With LED indication Yes

Number of buttons 1

Operation

operating areas configurable as one or two-area

operation

Electric current

Subject to technical modifications

Bus current consumption (data transfer) max. 20 mA

Dimensions

Labelling field length (W x H) 52.3 x 52.8 mm

Height 55.3 mm

Width 55.8 mm

Power

Power consumption, KNX ≈ 150 mW

Measurement

Value transmitter

value transmitter for dimming, position, brightness

and temperature values 1 and 2 byte

Screen

With display No

Materials

Colour of design line aluminium/anthracite

Colour independent of design lines for anthracite and aluminium

Colour aluminium/anthracite

RAL colour RAL 7016 - Anthracite grey

Material thermoplastic

Material for printing Paper

Type of surface treatment untreated

Material family Plastic

LED control

LED

with white operating LED, with 2 RGB status LEDs

per rocker

Connection

Bus coupling unit for bus coupling unit flush-mounted

Settings

Supported configuration modes system, easy

Parameterisation

single and two push-button operation

parameterisable

Scope of delivery

Bus connection included No

Equipment

Number of actuation points 2

With anti-theft/dismantling protection Yes

Product type: product type: push-button 1gang

Use

Differentiation characteristic 1 - Sales with labelling field

Differentiation characteristic 2 - Sales and RGB LED

Differentiation characteristic 3 - Sales with integrated temperature sensor

Subject to technical modifications
