WARNING!!!

(Risk of death; Prevention of accidents)

•

Do not look directly at the light source. In addition, when mounting

the light unit, ensure that the light would not dazzle other road users.

• To prevent accidents and to ensure safe riding, make sure the

light is securely attached to the bracket and it is functioning

properly without being unobstructed before the ride.

• Always pay attention to the remaining battery power by

checking the indicator periodically while using the light.

•

Do not disassemble or modify the light or any of the included items.

CAUTION!

(Prevention of injury, damage, or property damage)

• Be sure to tighten the dial by hand. When you tighten it too

hard with a tool, the screw thread may be stripped.

• Check the dial and screw on the bracket periodically, and use

them without any loosening.

• Operating the light while riding is dangerous. Always ride safely.

• Do not use Ultra Boost or High mode on public roads.

• Note that the light becomes hot while illuminated. Do not

block the lens or cover the light.

• Due to the variability of LEDs, the color and brightness may

differ even between devices with the same model number.

• Keep device out of the reach of children.

•

Carrying a spare headlight is recommended in case the battery runs out.

•

When used with a cyclocomputer, attach the headlight as far away

from the cyclocomputer as possible, as it may affect measurement.

• This device is rated IPX4 based on JIS C0920. Do not immerse

the device in water. Doing so may cause a malfunction. Wipe off

any moisture after using the device in rainy weather.

• Do not subject the light to strong vibrations, impacts, or

excessive force. Discontinue use if any abnormality occurs.

• Do not charge or use the battery at any voltage or polarity

other than that specified. Do not short-circuit the battery.

• Do not drop the light into a fire or heat the light.

• If the light unit or parts become dirty with mud, etc., clean

with a soft cloth moistened with mild soap. Never apply paint

thinner, benzine or alcohol; damage will result.

LITHIUM-ION BATTERIES

Recharge the battery for first time use or after long period of storage :

The voltage of the battery may drop due to self-discharge

during long period of storage.

• Always fully charge the battery before use.

• If the device will not be used for a long period of time, store

it in a location that is not too hot or too humid.

• Charge the battery for about 30 minutes every 6 months.

Cautions for charging and usage :

•

Charging, discharging, and storing in high temperatures will cause

the rechargeable battery to deteriorate faster. Do not place the light

inside a vehicle or near a heater. Make sure to charge only when the

ambient temperature is between 5 and 40°C.

• Please be sure that no dust or other foreign objects are

attached to the plug of the USB cable before charging.

• Do not apply a load to the connector port by hanging the

light unit during charging.

• Do not subject the light to vibrations while charging.

• Once charging is completed, be sure to disconnect the USB

cable from the charging port.

• After charging is complete, securely attach the charging port

cover to ensure waterproofing before riding.

• Charging and lighting times are approximate values, and will

vary by environmental and user conditions.

•

If the illumination time is significantly reduced

even after proper charging, the rechargeable

battery may be nearing the end of its service life.

Cautions for dispose :

When disposing the light unit, please do so in

accordance with your local regulations.

Design Pat. Pending

HLEL2200RC-240228

Before using the product, be sure to read this manual thoroughly and keep it

available for future reference. If a child uses it, the child’s guardian must

read the manual and explain the precautions for use to the

child. This product is developed assuming use by bicycle.

Do not use the product in any way other than as described

in this manual.

RECHARGEABLE HEADLIGHT

MODEL : HL-EL2200RC

Required Items

Please prepare a USB cable (Type-C) that can be used for charging (sold separately) before using this product.

Use a 2 A or higher USB battery charger. The unit may not charge properly if less than 2 A.

* To ensure safety, do not charge the battery if the light unit is hot.

Be sure to release Lock mode before use.

This device is equipped with a lock mode to prevent accidental operation. Lock mode is

enabled by default. To release Lock mode, press and hold the switch for about 8 seconds.

Before using the product, refer to the “LITHIUM-ION BATTERIES” section

and charge the battery.

Approx.

Constant

red light

Off

Charging

Charging is

completed

Charging time

(

)

Light unit Bracket

(

H-34N :

FlexTight™

)

Switch (Indicator)

Dial

The USB cable is not included in the

package because CATEYE is

committed to making environmentally

friendly and resource-saving products.

CATEYE will continue to contribute to society by creating

new values in “Safety,” “Health,” and “Environment”.

CATEYE supports the Sustainable Development Goals

movement proposed by the United Nations.

ECO FRIE NDLY

( www.cateye.com/intl/company/sdgs/ )

Press and hold

*4 *4

Double-click

Click

HighHighUltra BoostUltra Boost MiddleMiddleLowLow

FlashingFlashing

Daytime

HyperConstant

Daytime

HyperConstant

EnduroEnduro

OFF

LOCK

MODE

LOCK

MODE

How to mount to a bicycle

Dial

(

Vertical adjustment

)



Screw

(

Horizontal adjustment

)

To adjust the angle, loosen the dial

or the screw to the point that the

bracket moves slightly, make the

adjustment, and then tighten the

screw to fix the light unit in place.

Insert the

product until it

clicks into place.

Mounting

Press the release

tab toward the

light unit and pull

to remove.

Removing

Φ 22-35 mm

Better

When mounting the light

unit, ensure that the light

would not dazzle other

road users.

When mounting the light

unit, ensure that the light

would not dazzle other

road users.

Remaining

battery power

Approx.

50% or more

Constant blue

light

Approx.

50 - 20%

Constant

orange light

Less than

Approx. 20%

Constant red

light

If the indicator turns red, charge the product as soon as possible.

If the indicator

lights up red when

the switch is

clicked, Lock mode

is enabled.

When turning the light on, it lights up in the mode that was used last time. (Mode memory function)

While enabling Lock mode, the indicator will flash red and the light will flash temporarily. After the light

stops flashing, Lock mode will be enabled.

The indicator will flash after lighting up red when Lock mode is released. After the indicator stops flashing

and Lock mode is disabled, Enduro mode will be enabled.

A protection circuit will be activated if the light unit becomes too hot, and the brightness of the light will be reduced.

This is not a malfunction. The light will return to the original brightness when the temperature cools to a safe level.

Press and hold

Standard accessories

Use only genuine components to prevent accidents and malfunctions.

Optional accessories

Bracket Spacer

(

H-37AL

)

5340910

USB cable

(

Type-A

↔

Type-C

)

5342550

Bracket

(

H-34N

FlexTight™

)

5338827N

Bracket

(

Helmet mount

)

5341831N

Bracket

(

CFB-100

Center fork

)

5342440

Bracket

(

OF-200

Out-front 2)

1604110

Light source LED x 1

Battery type Li-ion 3.6 V - 5000 mAh

Charge terminal USB TYPE-C

Operating time Ultra Boost

：

Approx. 1 hours

High

：

Approx. 1.5 hours

Middle

：

Approx. 2.5 hours

Low

：

Approx. 5 hours

Enduro

：

Approx. 12 hours

Daytime HyperConstant

：

Approx. 4 hours

Flashing

：

Approx. 60 hours

* Approximate average runtime at 68°F (20°C).

Charging time Approx. 4 hours (2 A)

Charge voltage 5 V

Temperature range

Charging : 41°F – 104°F (5°C – 40°C) Operating : 14˚F – 104˚F (-10˚C – 40˚C)

Waterproof IPX4

Recharge / discharge number of times

About 300 times (until the rated capacity drops to 70%)

Dimensions / Weight

1-22/32” x 4-39/64” x 1-37/64” (43.5 x 117 x 40 mm) / 7.53 oz (213.5 g)

* The specifications and design are subject to change without notice.

2-year Warranty: Light unit only (excludes battery deterioration)

CatEye products are warranted to be free of defects from materials and workmanship for a

period of 2 years from original purchase. If the product fails to work during normal use, CatEye

will repair or replace the defect at no charge. Service must be performed by CatEye or an

authorized retailer. To return the product, pack it carefully and enclose the warranty certificate

(proof of purchase) with instruction for repair. Please write or type your name and address

clearly on the warranty certificate. Insurance, handling and transportation charges to CatEye

shall be borne by person desiring service. For UK and REPUBLIC OF IRELAND consumers,

please return to the place of purchase. This does not affect your statutory rights.

SPECIFICATIONS LIMITED WARRANTY

2-8-25, KUWAZU, HIGASHI SUMIYOSHI-KU, OSAKA, JAPAN 546-0041

For inquiries, please visit https://cateye.com/intl/contact/

CO.,LTD.

[For US Customers]

CATEYE AMERICA, INC.

Please visit https://www.cateyeamerica.com/contact-us/

Toll Free : 800.5.CATEYE
