Manual

K 1187

RECHARGEABLE HEADLIGHT

HL-EL350G RC

2.4v

ENG

Design Pat. Pending

HLEL350GRC-18053

SPECIFICATIONS

Battery : AA Ni-MH 2.2Ah (GP220AAH) rechargeable

battery x 2, or AA alkaline battery x 2

Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)

Recharge / discharge number of times

: About 300 times (until the rated

capacity drops to 70%)

Dimensions / weight :

1-39/64” x 3-37/64” x 1-7/16” (41

x 91 x 36.5 mm) / 3.63 oz (103 g)

* The specifications and design are subject to change

without notice.

LIMITED WARRANTY

2-year Warranty: Light unit only

(Deterioration of the battery is excluded.)

CatEye products are warranted to be free of defects from

materials and workmanship for a period of 2 years from

original purchase. If the product fails to work during

normal use, CatEye will repair or replace the defect at no

charge. Service must be performed by CatEye or an

authorized retailer. To return the product, pack it carefully

and enclose the warranty certificate (proof of purchase)

with instruction for repair. Please write or type your name

and address clearly on the warranty certificate. Insurance,

handling and transportation charges to CatEye shall be

borne by person desiring service.

PRECAUTIONS ON USE

• Before your trip, please make sure the light is firmly

mounted to the bracket, it lights up, and the light is

not blocked by baggage, etc.

• Do not place it within children’s reach.

• Do not use a dry battery (primary battery) together

with a rechargeable battery. Do not use a new battery

in combination with an old battery.

• Be sure to install batteries in the correct direction.

• In preparation for unexpected battery shutoff, we

recommend you carry a spare battery.

• Mounting the light unit too close to a wireless

computer may adversely affect the reading of the

computer.

• Remove and store batteries when you will not use the

light for a long period of time. Otherwise, batteries

may leak liquid, which may result in failure.

• This product is water-resistant under normal daily

use and can be used in the rain. However, do not

intentionally submerge it in water.

• If the light unit or parts become dirty with mud, etc.,

clean with a soft cloth which is moistened with mild

soap. Never apply paint thinner, benzine or alcohol;

damage will result.

WARNINGS AND PRECAUTIONS ON

CHARGING

• Do not charge when dry batteries are installed.

• Be sure to charge the CatEye genuine rechargeable

battery only as prescribed.

• Commercially available rechargeable batteries should

be charged with a compatible battery charger.

• We recommend using 500+mA (USB2.0) USB battery

charger.

• When your PC is in sleep state, the unit cannot be

charged.

• Charging and lighting times are approximate values,

and will vary by environmental and user conditions.

• Dispose of the rechargeable battery appropriately

according to local regulations.

PRECAUTIONS WHEN MOUNTING

• Be sure to tighten the dial by hand. When you tighten

it too hard with a tool, the screw thread may be

stripped.

• Round off the cut edge of the bracket strap to prevent

injury.

• To re-adjust the beam angle, loosen the dial enough

to move the bracket, and firmly tighten it after

adjustment.

USB cable

(MICRO USB)

5342730

USB cable

(MICRO USB)

x 2

Charge jack cover

* If the indicator flashes, there is a charging error.

Remove the cable and try again.

Standard charging time

Approx.

4 h

(

USB 2.0

)

Charging

Charging is

completed

Switch (Indicator)

Slide the cover to the back

while pressing down on the

dot section.

How to remove

batteries

Insert the batteries

according to the marks on

the case.

HOW TO INSTALL BATTERY

Dot section

HOW TO CHARGE

Always charge the product before use.

In place of rechargeable batteries, AA batteries can

be used for this light.

WARNING!!!:

Do not charge when dry batteries are installed.

USB cable

To PC or USB

battery charger

HOW TO MOUNT TO A BICYCLE

Bracket Rubber pad

Dial

Strap

Release button

Screw

SWITCH OPERATION

It is recommended to use only rechargeable battery,

otherwise runtime may vary considerably.

*1 Check the dial and screw on the bracket

periodically, and use them without any loosening.

*2 When you turn the light on, it lights up in the last

lighting mode you used. (Mode memory function)

* When the switch (indicator) lights up, the

remaining battery power is 20% or less. Please

charge as soon as possible.

Approx.

9 h

Approx.

3.5 h

Switch (Indicator)

5338827N

FlexTight™

bracket

(H-34N)

5341890

Special nickelhydride

rechargeable battery

5342440

Center fork bracket

(CFB-100)

5341831N

Helmet mount

Rechargeable

battery

x 2

Light unit FlexTight™

bracket

(H-34N)

Press and hold

OFF ON

Click

High Low

Before using the light, please

read this manual and the

included separate sheet “NIMH

BATTERIES” thoroughly, and

keep them for future reference.

SPARE / OPTIONAL PARTS

2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka 546-0041 Japan

Attn : CATEYE Customer Service Section

Phone : (06)6719-6863

Fax : (06)6719-6033

E-mail : support@cateye.co.jp

URL : http://www.cateye.com

.,LTD.

(Ni-MH 2.2Ah GP220AAH)
