Manual

RECHARGEABLE HEADLIGHT

NO!

ENG

WARNING!!!

• Be sure to direct the light beam downward so

approaching car or pedestrian are not dazzled.

• Before your trip, please make sure the light is firmly

mounted to the bracket and it lights up.

• Always pay attention to the remaining battery power

by checking the indicator periodically while using the

light.

CAUTION!

• Keep the light away from children.

•

Mounting the light unit too close to a wireless computer

may adversely affect the reading of the computer.

• In preparation for unexpected shutoff, we recommend

you carry a spare light.

• This product is water-resistant under normal daily

use and can be used in the rain. However, do not

intentionally submerge it in water.

• If the light unit or parts become dirty with mud, etc.,

clean with a soft cloth which is moistened with mild

soap. Never apply paint thinner, benzine or alcohol;

damage will result.

LITHIUM-ION BATTERIES

Cautions on recharging

•

Avoid charging in direct sunlight or in a vehicle parked

under direct sunlight, and make sure to charge only

when the ambient temperature is between 41°F and

104 °F (5 and 40°C).

• Before charging, be sure that no dust or other foreign

objects are attached to the USB plug.

• Do not subject the light to vibrations while charging.

• Once charging is complete, be sure to disconnect the

USB plug.

Cautions in use

• Charging, discharging, and storing in high

temperatures will cause the rechargeable battery to

deteriorate faster.

Do not place the light inside a vehicle or near a heater.

• If the illumination time is significantly reduced even

after proper charging, the rechargeable battery may

be nearing the end of its service life. Dispose of the

battery as described in “Cautions for disposal”.

Cautions on storage

Cool and dry storage is recommended. For long period

storage, it is important to charge the battery 30 minutes

every 6 months.

Cautions for dispose

When disposing of the light unit, dispose of it

according to local regulations.

HOW TO CHARGE

HOW TO MOUNT TO A BICYCLE

Light unit FlexTight™ bracket

(

H-34N

)

Before using the light, read this manual

thoroughly and keep it for future

reference.

USB cable

(

MICRO USB

)

1 2

1. Mount the bracket to the

handlebar. (Fig.2 – )

2. Insert the light unit into the

bracket until it clicks, and

adjust the beam angle. ( )

(*1)

3. To remove the light unit, pull it

forward while pressing down

on the release button ( , ).

* To readjust the beam angle,

loosen the dial and/or the

screw enough to move the

bracket, and firmly tighten

them after adjustment. (*2)

5 6

Before Initial Use

This unit is shipped with small charge to check the

light. Be sure to charge it before use, according to

the instructions “HOW TO CHARGE” and

“Cautions on recharging”.

CAUTION!:

• Be sure to tighten the dial by hand. If tightened too hard with a tool, the screw thread may be stripped.

• Check the dial and screw (*2) on the bracket periodically, to monitor for any loosening.

• If cutting the strap, be careful of injury from where the strap is cut. (*3)

Indicator

Approx.

(1A)

- 8

(0.5A)

Charging

Steady

red light

Off

Charging is

completed

Standard charging time

Charge jack cover

USB cable

To PC or USB battery charger

1. Connect the light unit to your PC or a commercial USB battery charger using the USB cable. (Fig.1 – ).

The indicator turns red and charging starts.

* When your PC is in sleep state, the unit cannot be charged.

* Use a USB battery charger of 500 mAh (USB2.0) or more.

2. Once charging is complete, disconnect the USB cable and securely attach the charge jack cover.

CAUTION!: Attach the charge jack cover securely to ensure waterproofness.

* Charging and lighting times are approximate values, and will vary by environmental and use conditions.

Bracket

Dial

Strap

Rubber pad

Release

button

Screw

*4 When turning the light on, it lights up in the mode that was used last time. (Mode memory function)

ONOFF

Low

Daytime

HyperConstant

Flashing

High

Switch (Indicator)

Press

and hold

Press and hold

Click

Double-click

Remaining battery capacity :

When the switch is illuminated in red, there is little remaining

battery power. Please charge as soon as possible.

SWITCH OPERATION

Switch

(Indicator)

HL-EL085RC

Design Pat. Pending

HLEL085RC-190603

5342730

USB cable

(

MICRO USB

)

5338827N

FlexTight™ bracket

(

H-34N

)

5342440

Center fork bracket

(CFB-100)

5341831N

Helmet mount

SPARE/OPTIONAL PARTS

SPECIFICATIONS

Light source High-intensity LED x 1

Battery Li-ion 3.6 v 2200 mAh

Charge Micro USB plug

Operating time High : Approx. 1.5 hours

Low : Approx. 3 hours

Daytime HyperConstant : Approx. 5 hours

Flashing : Approx. 50 hours

* Average runtime at 68˚F (20˚C).

Standard charging time

Approx. 4 (1A) – 8 (0.5A) hours

Temperature range Charging : 41˚F – 104˚F (5˚C – 40˚C)

Operating : 14˚F – 104˚F (-10˚C – 40˚C)

Recharge/discharge number of times

About 300 times (until the rated capacity drops to 70%)

Dimensions/weight 1-11/32” x 3-15/16” x 1-29/64” (34 x 100 x 37 mm)

/ 4.13 oz (117 g)

* The specifications and design are subject to change without notice.

LIMITED WARRANTY

2-year Warranty: Light unit only

(

excludes battery deterioration

)

CatEye products are warranted to be free of defects from materials and workmanship for a

period of 2 years from original purchase. If the product fails to work during normal use,

CatEye will repair or replace the defect at no charge. Service must be performed by CatEye

or an authorized retailer. To return the product, pack it carefully and enclose the warranty

certificate (proof of purchase) with instruction for repair. Please write or type your name

and address clearly on the warranty certificate. Insurance, handling and transportation

charges to CatEye shall be borne by person desiring service.

For UK and REPUBLIC OF IRELAND consumers, please return to the place of purchase.

This does not affect your statutory rights.

2-8-25, Kuwazu, Higashi Sumiyoshi-ku,

Osaka 546-0041 Japan

Attn: CATEYE Customer Service Section

Phone : (06)6719-6863

Fax : (06)6719-6033

E-mail : support@cateye.co.jp

URL : https://www.cateye.com

.,LTD.

[For US Customers]

CATEYE AMERICA, INC.

2825 Wilderness Place Suite 1200, Boulder CO

80301-5494 USA

Phone : 303.443.4595 Toll Free : 800.5.CATEYE

Fax : 303.473.0006 E-mail : service@cateye.com
