Side 1/2

NO!

Indicator

(Constant red light)

Remaining battery capacity:

When the switch (battery indicator) is illuminated in red, there is little

remaining battery power. Replace the battery as soon as possible.

ENG

Design Pat. Pending

HLEL370G-191010

WARNING!!!

• Be sure to direct the light beam downward so

approaching car or pedestrian are not dazzled.

• Before your trip, please make sure the light is

firmly mounted to the bracket and it lights up.

• Always pay attention to the remaining battery power

by checking the battery indicator periodically while

using the light.

CAUTION!

• Keep the light away from children.

• Mounting the light unit too close to a wireless

computer may adversely affect the reading of the

computer.

• This product is water-resistant under normal daily

use and can be used in the rain. However, do not

intentionally submerge it in water.

• If the light unit or parts become dirty with mud,

etc., clean with a soft cloth which is moistened with

mild soap. Never apply paint thinner, benzine or

alcohol; damage will result.

HOW TO REPLACE BATTERY

HOW TO MOUNT TO A BICYCLE

Light unit FlexTight™ bracket

(

H-34N

)

Before using the light, read this manual

thoroughly and keep it for future reference.

5338827N

FlexTight™ bracket

(

H-34N

)

5341831N

Helmet mount

SPARE/OPTIONAL PARTS

SPECIFICATIONS

5 6

1. Slide the cover backward while pressing

on the dot section (Fig.1 , ).

2. Insert the batteries on top of the belt

according to the orientation marked on

the unit ( ).

3. Reattach the cover by following the

procedure in reverse.

CAUTION!

• Do not use rechargeable batteries.

• Do not combine old and new batteries or batteries of

different types.

• Ensure correct polarity when installing the batteries.

• Remove the batteries if the light will not be used for a long

time. Failure to do so may result in malfunction due to

battery fluid leakage.

Manual

BATTERY HEADLIGHT

HL-EL370G

K 1682

Dot section

Cover

Belt

Pull

Belt

Alkaline AAA

batteries

× 3

1 2

Removing the battery

Mounting height : 400 – 1200 mm

Bracket

Rubber pad

Strap

Dial

Release button

Screw

1. Mount the bracket to the handlebar. (Fig.2 – )

2. Insert the light unit into the bracket until it clicks, and

adjust the beam angle. ( ) (*1)

3. To remove the light unit, pull it forward while pressing

down on the release button ( , ).

* To readjust the beam angle, loosen the dial and/or the

screw enough to move the bracket, and firmly tighten them

after adjustment. (*2)

CAUTION!

• Be sure to tighten the dial by hand.

If tightened too hard with a tool, the screw thread may be stripped.

• Check the dial and screw (*2) on the bracket periodically, to monitor for any loosening.

• If cutting the strap, be careful of injury from where the strap is cut. (*3)

ONOFF

When turning the light on, it lights up in the mode that was used

last time. (Mode memory function)

*4:

Switch

(Battery indicator)

Switch : Press and hold

SWITCH OPERATION

Click

High Low

Light source High-intensity LED x 1

Battery Alkaline AAA batteries 1.5 V x 3

Operating time High : Approx. 3 hours

Low : Approx. 10 hours

* Average runtime at 68˚F (20˚C).

Temperature range 14˚F – 104˚F (-10˚C – 40˚C)

Dimensions/weight 1-11/32” x 1-1/2” x 3-23/64”

(34 x 38 x 85.5 mm) / 2.33 oz (66 g)

* The specifications and design are subject to change without

notice.

LIMITED WARRANTY

2-year Warranty: Light unit only

CatEye products are warranted to be free of defects from materials and workmanship for a period of 2 years from

original purchase. If the product fails to work during normal use, CatEye will repair or replace the defect at no

charge. Service must be performed by CatEye or an authorized retailer. To return the product, pack it carefully and

enclose the warranty certificate (proof of purchase) with instruction for repair. Please write or type your name and

address clearly on the warranty certificate. Insurance, handling and transportation charges to CatEye shall be

borne by person desiring service.

2-8-25, Kuwazu, Higashi Sumiyoshi-ku,Osaka 546-0041 Japan

Attn: CATEYE Customer Service Section

Phone : (06)6719-6863 Fax : (06)6719-6033

E-mail : support@cateye.co.jp URL : https://www.cateye.com

.,LTD.
