Side 1/15

Read this user manual and in

particular the safety notes,

before using the product.

Keep the user manual for future

reference and include it when passing the

product on to third parties.

Esprinet S.p.A. will not in any way be held

responsible for injury or damage caused to

persons or property arising from misuse of

the product.

Safety notes

Avoid listening at extreme volumes,

particularly for prolonged periods of time

when using the product.

If you use the product at an excessively high

volume, you could permanently damage your

hearing. Listen at a moderate volume.

Be aware of how these signals diﬀer in terms

of their sound so that you are able to recognize

the signals in corresponding situations.

Observe the legal regulations and provisions in

the country where you use the product.

To prevent malfunction or damage to the

product, avoid accidental falls, do not crush,

puncture or exercise a high level of pressure

on the product.

Do not store or expose your product to any

source of heat, direct sunlight, radiators,

stoves or other heat sources such as the

dashboard of your car in the summer.

Do not try to modify, repair or disassemble the

product.

Do not use a damaged product.

Do not under any circumstances use

aggressive cleaning agents, alcohol or other

chemical solutions for cleaning as they can

damage the housing or even impair the

functionality of the product.

ere are no serviceable parts inside the

product. Never open/disassemble it.

Keep the product out of reach of children.

Never allow children or persons with

disabilities to use electrical products without

supervision.

Make sure children do not remove any small

parts from the product: they may swallow

them when playing and suﬀocate.

Charging

For the ﬁrst use, recharge the device until

it is fully charged. To recharge the product,

use the included charging cable. e red light

indicates that the product is in the charging

state, when the light goes out the device will

be fully charged.

Pairing

Place the speaker and pairing device within

1 meter of each other. Enable the wireless

function of the device you intend to pair with.

Activate your pairing device’s wireless feature.

Search for “BOOST” and select it to connect. If

a password is requested, key in “0000”.

Automatic reconnection

Once the product and the pairing device

have been paired, they will automatically

reconnect if they are within a short distance

of each other and the pairing device's wireless

function is enabled.

TWS function

1. Power on 2 BOOST speakers at the same

time, a blue light will ﬂash on both. Press the

TWS button on one of the two speakers, after

a few seconds the speakers will pair with each

other, a steady green light will appear on both.

2. Open the wireless menu on your device,

Search for the device from the wireless menu

and select "BOOST" to start the connection

3. Once pairing is complete, you will hear a

sound, a blue light will ﬂash on both speakers.

It is now possible to play music from both

speakers simultaneously.

4. Press the TWS button on either speaker to

exit TWS mode. Press the TWS button again

to pair again, Two previously paired speakers

will automatically reconnect once turned on.

Multifunction buttons Cleaning

Do not use solvents, corrosive agents or

gaseous cleaners.

Technical speciﬁcations

Wireless version: 5.0

Water resistance: IPX6

Input: DC 5V/1A

Battery life: 4h

Software: 5.0

Charging time: 3.5h

Speaker diameter: 57mmØ

Impedance: 4Ω

Frequency response: 90Hz ~ 18KHz

Frequency: 2,408-2,480 GHz

Maximum radiated power: <20mW

Output: 5W

Battery: 3,7V / 1200mAh, 4,44Wh

Size: 8x8x10,5cm

Weight: 373g

Wireless range: 10m

Usage temperature: 0-40 °

CUSTOMER’S INFORMATION FOR

RIGHT WASTE OF THIS PRODUCT

(Directive 2013/56/EU)

is marking on the product or its packaging

means that the product at the end of its life,

inlcuding the unremovable battery, must

be separated from other types of waste to

recycle it responsibly.

Safely’s use of this product is guaranteed from

the respect of this instructions manual, keep it

and carefully use it for all life of the product.

e product doesn’t need any kind of technical

maintenance, NEVER DISASSEMBLE IT.

e battery inside the product is integrated

and not replaceable. Don not try to remove

li-ion/polymer battery included in inside the

product because can produce overheat’s

danger, burning and injury. e battery must

be removed only by qualiﬁed professional

techincians, that are able to remove it without

any kind of danger and to recycle it in the

respect of the law. Users should give free end

of life product into the local separate collection

centers or to the retailer, in reason of one to

one, or free if the product size is bigger than

25 cm. Adequated waste disposal permit to

award the product to recycling, treatment

with ecofriendy compatible disposal conduce

to prevent possible harm to the environment

or human health and promote the reuse and/

or product materials recycling. Unauthorized

waste disposal of electronic product, cell and

battery from houseold user involve currency

legislation sanctions.

is product complies with the

RoHS directive 2011/65 / EU -

2015/863 / EU. e Product has

the CE mark and therefore complies with the

safety standards established by the European

Union.

Esprinet SpA declares that the product

complies with directive 2014/53 / EU.

e full text of the EU declaration of

conformity is available at the following

internet address:

www.celly.com/exchange/CELLY-SPA/

Dichiarazioni_di_conformita/BOOST/DOC_

BOOST.pdf

Celly® is a trademark owned by CELLY

S.p.A.

All brands are registered trademarks of

their respective owners.

Esprinet S.p.A., via Energy Park

20, 20871 Vimercate (MB) -

Italy

Made in China.

Instruction manual

WIRELESS SPEAKER

Model: BOOST

Rev00 - 25.11.2021

FUNCTION SINGLE CLICK LONG PRESS

POWER // ON/OFF

+ NEXT TRACK VOLUME +

- PREVIOUS TRACK VOLUME -

PLAY/PAUSE PLAY/PAUSA //

M WIRELESS ON/OFF //

TWS TWS ON/OFF //

Produkt Specifikationer

Mærke:	Celly
Kategori:	Højttaler
Model:	Boost
Bredde:	80 mm
Dybde:	105 mm
Højde:	80 mm
Vægt:	373 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Batterikapacitet:	1200 mAh
FM radio:	Ingen
Batteriteknologi:	Lithium polymer (LiPo)
Antal højttalere:	1
Udgangseffekt (RMS):	5 W
Husmateriale:	Plast
Beskyttelsesfunktioner:	Vandtæt
Pakketype:	Hængende boks
Impedens:	4 ohm (Ω)
Forbindelsesteknologi:	Trådløs
Standby tid:	120 t
Indbygget kortlæser:	Ingen
3,5 mm stik:	Ja
USB-tilslutning:	Ja
Batteritype:	Indbygget batteri
AUX-indgang:	Ja
Opladningstid for batteri:	3.5 t
Indbygget mikrofon:	Ingen
Driver diameter:	57 mm
USB-stik type:	Micro-USB
Produktdesign:	Cylinder
USB-opladningsport:	Ja
Krog:	Ja
